“I want technology to enhance my work without hindering it. It's gotta be versatile, portable, and it's got to keep up my pace of life.”
M1+_G2
Smart Portable Projector with Harman Kardon® Speakers
- Smart Wi-Fi & Bluetooth connectivity
- 360° Smart stand that allows for ceiling projection
- Integrated stereo Harman Kardon speakers
- Cinema SuperColor+™ Technology with 125% Rec.709
- Advanced light source with a 30,000-hour lifespan
- Up to 6 hours of battery life
OVERVIEW
The ViewSonic M1+_G2 is an iF award-winning, ultra-portable LED projector that can deliver a convenient, enjoyable entertainment experience anywhere it goes. With a built-in battery, a LED light source with up to 30,000 hours of lifespan, all packaged into less than 1 kg, the M1+_G2 can deliver years of multimedia entertainment wherever it goes – from room to room, both inside and outdoors. Its smart stand enables simple 360-degree setup, while doubling as a lens cover. Once the lens is uncovered, the projector automatically powers on to full brightness for instant entertainment. Stereo Harman Kardon speakers provide room-filling sound for an amplified experience, while more flexible audio needs can be realized via Bluetooth. Integrated Wi-Fi connectivity makes streaming easier than ever – both wireless casting from smart devices and built-in content streaming are possible.Express Yourself Anywhere You Go
M1+_G2 Portable Cinema
iF Award Design
Metal Stand
Sturdy setup anywhere - no tripod needed.
Lens Cap
The stand also doubles as a lens cover to protect the lens from being damaged when being transported.
Power Combo
Swiveling the stand to uncover the lens powers the projector on in an instant.
Mirror the Screen from Your Phone,
to the Projector
Projecting your phone screen to the projector has never been easier.
Wirelessly connect the M1+_G2 to your smart device* and enjoy big screen entertainment.
*iPhone and Android phones are supported and they need to be connected under the same network as M1+_G2.
Intuitive Touch Control with your phone
Now you can turn your mobile device into an alternative powerful remote control – intuitive touch control, easy typing, and simple annotation on the big screen. Simply download the ViewSonic vCastSender app on your phone, make sure your phone and the projector are connected to the same Wi-Fi network, and pair them up in the app to get started.
Room-Filling Sound
Dual speakers by Harman Kardon deliver vibrant treble, balanced mids, and strong bass for an all-around immersive experience whether you’re watching movies, music videos or listening to a live concert.
Movie Mode
Situate yourself in the movies; home theater made perfect.
Music Mode
Balanced tuning to deliver you the authentic touch of original melodies.
User Mode
With our professional DSP technology, you can customize the way you want to enjoy the audio.
Bluetooth for Flexible Audio Needs
Turn the M1+_G2 into a Bluetooth speaker to play your favorite music in high quality and amplify the pleasure.
Or the other way around, output the audio of a thrilling game from the projector to your own Bluetooth headphones, immersing yourself in your own big screen fun.
Projection in Every Direction
M1+_G2 is the perfect companion for lazy Sundays when you just want to relax and unwind.
Whether you’re curled up in bed or lounging around on the sofa, watching the latest episode of your favorite TV show is more comfortable than ever with M1+_G2’s 360-degree perfect projection that lets you project images onto the ceiling, wall, floor or anywhere you please – with ease.
Perfectly Proportioned Images Every Time
Say goodbye to distorted images for good. M1+_G2 projects perfectly proportioned images at every angle via the auto keystone feature that corrects images automatically from any angle.
Auto keystone
True-to-life Colors,
Fill You with Wonder
True-to-life colors offered by ViewSonic’s proprietary Cinema SuperColor+™ Technology with 125% Rec.709 give you the vivid touch and feel for rich emotional pleasure.
Cinematic Experiences On-The-Go
M1+_G2 is a must-have for your next camping trip or outdoor excursion.
The built-in battery provides up to 6 hours* of entertainment for you and can be extended easily with a power bank via USB Type-C**, so you don’t have to deal with tangled cords or plug the projector into a power source.
* 6 hour battery life is in Battery saving mode
** To power on the projector, the power bank should be at least 45W (15V/3A) and support Power Delivery (PD) protocol output.
Stream Shows on Your Phone,
Project Them Anywhere You Go
M1+_G2’s USB Type-C connection puts a fun twist on streaming videos and facetiming your friends by allowing you to project content directly from your phone, laptop or tablet while also charging them simultaneously.
You can even play Switch games on the big screen via direct connection without the dock.
*Only available for devices that support USB Type-C video streaming
*For iPhone and iPad, users need to buy Apple-authorized Lightning to HDMI adaptor
Fit for Spaces of All Shapes and Sizes
Project 100’’ images from only 2.6 meters away – perfect for usage in small spaces.
Palm Sized
The M1+_G2 is small enough to fit in the palm of your hand and weighs 700g – making it easy to put in your bag or suitcase for presentations on-the-go.
Plug & Play
M1+_G2 has a versatile array of connectivity including HDMI and USB Type-C for connecting to your laptop, phone or tablet as well as USB and MicroSD drives. 12GB of local storage allows you to save your favorite content directly onto the projector itself.
Smart UI for Intuitive Navigation
Free yourself from struggling finding the things you want. With our intuitive and user-friendly interface design, you can relaxingly navigate around, select a command, or add favorite applications to the menu.
Up to 30,000 Hours Light Source Life
LED technology offers up to 30,000 hours of usage – a significant upgrade when compared to traditional mercury lamp projectors.
Eye Care
Utilizing reflective light, which bounces off the wall or projector screen before hitting your eyes, the projector makes the viewing experience virtually blue light free, less invasive to your sight and reduces eyestrain over prolonged viewing periods.
TÜV-Certified
Antibacterial
Remote Control
Stay entertained, stay healthy.
Our antibacterial remote control adopts a special coating with silver ions, which prevents bacteria from attaching and remains effective even after a long period of use.
Green Design
Packaging for the M1+_G2 portable projector is paper-based, biodegradable, and 99% recyclable – all the right ingredients for leaving a smaller carbon footprint.
Exterior & Rear I/O Connectors
REVIEWS
“View So Neat with ViewSonic M1+_G2 Portable Projector”
“巧小的LED Projector 开箱&分享！超酷！房间里有它真的太幸福了啦～～”
“After a long day of work, it's time to relax and watch my favorite Korean drama at home with my fav soju and snacks, cause why not, let Netflix and chill. I usually use the No 1 LED Projector in Malaysia - ViewSonic M1+_G2 Smart Portable Projector to experience cinematic features at the comfort of my home. Let's chill while staying safe!”
“M1 Plus G2: My TV is Dead and This is the Replacement”
“I had 1 week with the new Viewsonic M1+_G2 and it exceeded my expectations!”
“Ini la family time saya, dengan bermodalkan dinding putih kosong dan M1+_G2, me and my family can watch movie anytime anywhere in any attire”
“Much can be said about the benefits and advantages of portable projectors – from convenience to eye health, there’s no doubt that they’re becoming increasingly popular. We take a look at the Viewsonic M1+_G2, a diminutive portable projector that’s packed with features.”
“How to Enhance Home Workout Experience (ft. I try Chloe Ting ABS Workout) *ads*”
SPECIFICATIONS
- SpecificationProjection System: 0.2" VGA
Native Resolution: 854x480
Brightness: 300 DLP
Contrast Ratio: 120000:1
Display Color: 1.07 Billion Colors
Light Source Type: DLP
Light Source Life (hours) with Normal Mode: up to 30000
Lamp Watt: RGB LED
Lens: F=1.7, f=5.5mm
Projection Offset: 100%+/-5%
Throw Ratio: 1.2
Optical Zoom: Fixed
Image Size: 24"-100"
Throw Distance: 0.64m-2.66m, (38"@1m)
Keystone: +/- 40° (V)
Audible Noise (Normal): 26dB
Audible Noise (Eco): 25dB
Local Storage: Total 16GB , (12GB available storage)
Input Lag: 41.5ms
Resolution Support: VGA(640 x 480) to FullHD(1920 x 1080)
HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Horizontal Frequency: 15K-102KHz
Vertical Scan Rate: 23-120Hz - InputHDMI: 1, (HDMI 1.4/ HDCP 1.4)
USB Type C: 1 (5V/ 2A)
Audio-in (Bluetooth): 1 (BT4.2)
USB Type A: 1, (USB2.0 Reader)
SD Card: Micro SD (32GB, SDHC)
Wifi Input: 1 (5Gn) - OutputAudio out (3.5mm): 1
Audio-out (Bluetooth): 1 (BT4.2)
Speaker: 3W Cube x2
USB Type A (Power): 1 , (USB2.0 - 5V/1A,, share with USB A Input)
- OthersPower Supply Voltage: Power adaptor: , Input: 100~240V, Output: 19VDC / 3.42A, , Battery:, 12000mAh(4000mAh 3.7Vx3), (2.5hrs@Normal, 3hrs@Eco)
Power Consumption: Normal: 35W , Standby: <0.5W
Operating Temperature: 0~40℃
Net Weight: 0.7kg
Dimensions (WxDxH) with Adjustment Foot: 151x126x40mm
OSD Language: English, French, Spanish, Thai, Korean, German, Italian, Russian, Swedish, Dutch, Polish, Czech, T-Chinese, S-Chinese, Japanese, Turkish, Portuguese, Finnish, Indonesian, India, Arabic, Vietnamese, Greek, Total 23 languages - Standard AccessoryPower Cord: 1
USB-C Cable: 1 (1m)
Remote Control: 1
QSG: Yes - Optional AccessoryCarry Bag: PJ-CASE-010
