VPC27-W55-O2-1B - ViewBoard OPS i7 slot-in PC with TPM

Windows 11 Pro (Windows 10 Pro Downgrade preinstalled)
Intel^® Core™ i7-10700T Powerful Intel Processor
16 GB DDR4 2666 RAM
Ample 512GB Storage
Intel UHD Graphics 630 Chipset
Faster WiFi
Platform Integrity

Downloads

Datasheet Media

Add to Compare

Skip to the beginning of the images gallery

Product Overview

The ViewSonic® VPC27-W55-O2-1B slot-in PC delivers smart whiteboard and smart meeting room functionality for ViewSonic ViewBoard® interactive displays. This slot-in PC module easily plugs into compatible displays and supports high-definition audio and video. With a powerful Intel® i7 processor, and fast SSD, the VPC27-W55-O2-1B provides the computing power needed for fast-moving educational or corporate environments. Flexible connectivity options include HDMI, VGA, USB 2.0, 3.0 and Type-C ports, as well as Giga LAN RJ45 and integrated WiFi 6 connection.

Overview

Awards

Specifications

Media Player Type: Slot-in PC
CPU Processor Type: Intel® Core™ i7-10700T
CPU Processor Speed: Base Frequency: 2.0GHz, Turbo: 4.5GHz
Cache: 16MB
Cores: 8
Threads: 16
Operating System: Windows® 10 Pro
SECURITY: TPM2.0, Secure Boot
HTML5, JavaScript and CSS: No
Graphic Chipset: Intel UHD Graphics 630
RAM: 16GB
Memory Type: DDR4 2666
Ethernet LAN: 10/100/1000 Gigabit Ethernet
Wifi: Wireless AX200 WIFI 6
Bluetooth: Bluetooth 5.2
Storage Capacity: 512GB
Storage Type: M.2 NVMe
Voltage: DC in +12V ~ +19V @ 3.42A, 65W
Temperature: 23-113°F (-5-45º C)
Humidity (non-condensing): 20-80%
Physical (in.): 8.0 x 4.7 x 1.2
Packaging (in.): 10.0 x 7.7 x 3.0
Physical (mm): 202.0 x 119.0 x 30.0
Packaging (mm): 254.0 x 196.0 x 77.0
Net (lbs): 2.2
Gross (lbs): 2.7
Net (kg): 1.0
Gross (kg): 1.2
Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
Regulations: cTUVus, FCC-B w/ ICES003, FCC ID+SDOC, CA IC, IC VOC, NOM, COFETEL, CE EMC, CE RED, CE LVD, CB, RoHS, REACH, WEEE, BSMI, NCC, BIS, WPC, RCM, MIC, VCCI, VNTA, CCC, SRRC
Package Contents: VPC27-W55-O2-1B, Quick start guide
Warranty: One-year limited warranty

Media Player Type: Slot-in PC
CPU Processor Type: Intel® Core™ i7-10700T
CPU Processor Speed: Base Frequency: 2.0GHz, Turbo: 4.5GHz
Cache: 16MB
Cores: 8
Threads: 16
Operating System: Windows® 10 Pro
SECURITY: TPM2.0, Secure Boot
HTML5, JavaScript and CSS: No

Graphic Chipset: Intel UHD Graphics 630

RAM: 16GB
Memory Type: DDR4 2666

Ethernet LAN: 10/100/1000 Gigabit Ethernet
Wifi: Wireless AX200 WIFI 6
Bluetooth: Bluetooth 5.2

Storage Capacity: 512GB
Storage Type: M.2 NVMe

Voltage: DC in +12V ~ +19V @ 3.42A, 65W

Temperature: 23-113°F (-5-45º C)
Humidity (non-condensing): 20-80%

Physical (in.): 8.0 x 4.7 x 1.2
Packaging (in.): 10.0 x 7.7 x 3.0

Physical (mm): 202.0 x 119.0 x 30.0
Packaging (mm): 254.0 x 196.0 x 77.0

Net (lbs): 2.2
Gross (lbs): 2.7

Net (kg): 1.0
Gross (kg): 1.2

Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
Regulations: cTUVus, FCC-B w/ ICES003, FCC ID+SDOC, CA IC, IC VOC, NOM, COFETEL, CE EMC, CE RED, CE LVD, CB, RoHS, REACH, WEEE, BSMI, NCC, BIS, WPC, RCM, MIC, VCCI, VNTA, CCC, SRRC
Package Contents: VPC27-W55-O2-1B, Quick start guide
Warranty: One-year limited warranty
