LS550WH - 3000 LED Lumens WXGA Short Throw LED Projector w/ 125% Rec. 709

Bright 3000 LED Lumens WXGA projector with 0.49 short throw lens and advanced visual features
Latest LED technology provides an extended lifespan of up to 30,000 hours
4 corner adjustment, and a 40-degree H/V keystone and 360 degree projection
This projector can be configured to automatically turn on and off
Schedule, and manage the projector remotely with Crestron, AMX, Extron, PJ Link, ATEN, and ViewSonic’s vController
Supports most media players, PCs, Macs, and mobile devices with inputs such as HDMI, and USB

| Datasheet | Media

Product Overview

Featuring 1280x800 WXGA resolution, 3,000 LED lumens of brightness and a short throw lens, the ViewSonic^® LS550WH is a lamp-free LED projector ideal for business and education. Its 0.49 short throw lens provides a 100” screen from just a few feet away, delivering exceptional space efficiency and freeing presenters from blinding lights. No matter the environment, expect stunning images and vivid colors, as this projector boasts 125% Rec. 709 color accuracy. With 2nd generation LED technology, the LS550WH eliminates the need to continuously swap out bulbs and dispose of toxic chemicals. In addition, an IP5X sealed optical engine prevents dust and moisture from entering the projector, ensuring impeccable image quality and a long maintenance-free lifespan of up to 30,000 hours.* An automatic on/off feature delivers efficiency and power savings, while 360° tilt angle projection delivers flexible setup in small- to medium-sized meeting rooms and classrooms. Whether for business or education, the ViewSonic LS550WH LED projector provides a picture-perfect presentation every time. *Lightsource lifespan may vary based on actual usage and other factors.

Overview

Advanced LED Light Source

This projector uses the latest solid-state LED technology that is both mercury-free and lamp-free, offering a greener, filter-free projector solution. The LED light source provides over 60,000 hours of usage* while consuming less than half the power of a typical LCD TV, thereby lowering your total cost of ownership.

*Lightsource lifespan may vary based on actual usage and other factors.

projector showing auto-on and auto-off features

Convenient Auto Power On/Off

This projector can be configured to automatically turn on for quick and easy startup whenever an active video input is detected. Conversely, when no signal is present, the projector will automatically power off after a user-defined amount of time.

split screen of a conference room using a projector showing a light environment and darker setting

Bright Images in any Environment

Packed with 2,000 ANSI lumens/3,000 LED lumens and a high contrast ratio, this projector produces bright images in nearly any environment

Large Images in Small Spaces

A short throw lens enables large images to be projected from short distances in small rooms. In addition, any blinding lights in front of the presenter, distracting shadows on the projected image, or glaring hotspots on the screen, are all eliminated because the projector’s light source is closer to the projection surface.

360-degree Orientation

A robust mechanical construction allows the projector to be installed in nearly any position, at any angle from floor to ceiling. You can mount the projector pointing straight down at the floor, or mount the projector upside-down at a 45-degree angle if need be.

projector with a laptop that is using network control

Comprehensive LAN Control

This projector comes equipped with Crestron, AMX, Extron and ViewSonic vController, which are all easy-to-use network management tools.

Awards

InfoComm Best of Show - LS550WH

Projector Central

Projectors

Jun 2022

Specifications

Screen Size: 60 - 300 in. / 1.5 - 7.6 m
Throw Distance: 0.63m-1.58m (100"@1.06m)
Throw Ratio: 0.49
Light Source (watt): RGB LED
Light Source Life, Normal (hours): 30000
Color Depth: 1.07 Billion Colors
Input Lag: 37ms
Display Resolution: WXGA (1280x800)
Light Source: LED
Display Resolution: 1280 x 800
Brightness (Lumens): 3,000 LED (2,000 ANSI)
Dynamic Contrast Ratio: 3,000,000:1
Aspect Ratio: 16:10
Keystone: Vertical (+ 36º/- 40º) / Horizontal (+/- 40º)
Frequency Horizontal: 15K~102KHz
Frequency Vertical: 23-120Hz
PC Resolution (max): 1920 x 1080
PC Resolution (min): 640 x 480
Mac® Resolution (max): 1920 x 1080
Mac® Resolution (min): 640 x 480
USB 2.0 Type A: 1
3.5mm Audio Out: 1
3.5mm Audio In: 1
Control (RS232): 1
HDMI 1.4 (with HDCP 1.4): 1
RCA Audio In (L/R): 1
Internal Speakers: 2W (x1)
Voltage: 100-240 VAC, 50-60Hz
Consumption (typical): 157W
Stand-by: <0.5W
Physical Controls: Keypad, Power key
On Screen Display: Display, Image, Power Management, Basic, Advanced, System, Information (See user guide for full OSD functionality)
Temperature: 32-104º F (0 - 40º C)
Kensington Lock Slot: 1
Net (lbs): 5.4
Gross (lbs): 7.8
Net (kg): 2.5
Gross (kg): 3.6
Packaging (in.): 14.4 x 11.8 x 7.4
Physical (in.): 11.5 x 8.7 x 4.5
Packaging (mm): 365.0 x 300.0 x 188.0
Physical (mm): 293.0 x 221.0 x 115.0
AV Control: AMX Certified, Crestron Certified, Extron Certified
Regulations: cTUVus
Package Contents: LS550WH projector, power cable, remote control, Quick Start Guide
Warranty: Three-year limited warranty on parts and labor, 1-year limited warranty on the light source, 1st year free Express Exchange® service. (One year Express Exchange Service requires product registration).
Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
