Тип: | 19” TN colour TFT active matrix SXGA LCD |
Коефіцієнт контрастності: | 500:1 (typ.) |
Кути перегляду: | 140° horizontal, 130° vertical (at 10:1) 160° horizontal, 140° vertical (at 5:1) |
Яскравість: | 250cd/m² (typ.) |
Display Area: | 37.6cm horizontal x 30.1cm vertical, 48.3cm diagonal |
Optimum Resolution: | 1280 x 1024 |
Час відповіді: | 4ms (Grey-to-Grey), 8ms (off-on-off) (typ.) |
Panel Surface: | Anti-glare |
Pixel Pitch: | 0.294mm |
Bandwidth: | 135MHz |
Colour Support: | 16.2M colours (6-bit+2-bit FRC) |
PC: | VGA up to 1280 x 1024 non-interlaced (max. 60Hz) |
Mac®: | Power Mac™ up to 1280 x 1024 non-interlaced (max. 60Hz) |
W x H x D mm: | 416 x 479 x 238 (with stand) 416 x 352 x 70 (without stand) |
LCD Monitor, power cable, 15-pin VGA video cable, DVI cable, audio cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) |
Please see: www.viewsoniceurope.com/UK/Support/warranty.htm |
Sync: | H/V separated (TTL), composite, sync on green |
Digital: | DVI-D (TMDS, 100 ohms) |
Analogue: | RGB analogue (0.7/1.0 Vp-p , 75 ohms) |
Frequency: | Fh: 24 - 82kHz, fv: 50 - 85Hz |
Analogue: | 15-pin mini D-Sub (detachable cable) |
Digital: | 24-pin DVI-D (detachable cable) |
Аудіо: | 3.5mm stereo audio line-in |
Живлення: | 3-pin (CEE22) |
Напруга: | AC 100 – 240V, 50/60Hz (auto switch), internal power supply |
Споживання: | <45 watt (max.), ≤1 watt in power save mode |
Basic: | Power on/off, menu [1], up, down, select [2] |
OSD: | Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), Audio adjust (volume, mute), colour adjust (sRGB, 9300K, 7500K, 6500K, 5400K, 5000K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number, website), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall |
температура: | 0°C - 40°C |
Вологість: | 10% - 90% (non-condensing) |
Нетто: | 6.3kg (with stand), 4.6kg (without stand) |
Meets TCO’03, ENERGY and Energy Star standards |
Kensington® security port |
VESA FPMPMI 100mm x 100mm |
Нахил: | Down 5°, Up 20° |
Height Adjustment: | 0~100mm |
Pivot: | 0°~90° |
Speakers: | 2 x 1 watt |
