Black |
Тип: | 20” Wide TN colour TFT active matrix WSXGA+ LCD |
Коефіцієнт контрастності: | 1000:1 (typ.), 2000:1 (DCR, typ.) |
Кути перегляду: | 170° horizontal, 160° vertical (at 10:1) 175° horizontal, 170° vertical (at 5:1) |
Яскравість: | 300cd/m² |
Display Area: | 43.3cm horizontal x 27.1cm vertical, 51.1cm diagonal |
Час відповіді: | 5ms (off-on-off) (typ.) |
Джерело світла: | Long life, 40000 (min.) |
Рідна роздільна здатність: | 1680 x 1050@60Hz |
Panel Surface: | Anti-glare (3H) |
Pixel Pitch: | 0.258mm |
Colour Support: | 16.7M colours supported (6-bit + 2-bit FRC) |
Pixel Clock: | 135MHz |
PC: | VGA up to 1680 x 1050 non-interlaced |
Mac®: | Power Mac™ up to 1680 x 1050 non-interlaced |
Physical With Stand: | 472 x 408 x 225 |
Physical Without Stand: | 472 x 327 x 65 |
W x H x D mm: | 526 x 448 x 127 |
LCD Monitor, power cable, 15-pin VGA video cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language) |
Динамік: | 2x2.5-watts |
Analogue: | 15-pin mini D-Sub (detachable cable) |
Digital: | 24-pin DVI-D (detachable cable) (HDCP enabled) |
Живлення: | 3-pin AC plug (CEE22) |
Напруга: | AC 100–240V, 50/60Hz (auto switch), internal power supply |
Споживання: | 38 watt (typ.), <1 watt in power save mode |
Basic: | Power, menu [1], up, down, select [2] |
OSD: | Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), auto white balance, OSD/power lock, memory recall |
температура: | 0°C–40°C |
Вологість: | 20%–90% (non-condensation) |
Net With Stand: | 4.9kg |
Брутто: | 6.4kg |
Frequency: | Fh: 24–82kHz, Fv: 50–75 Hz |
Sync: | H/V separate (TTL), composite, sync on green |
Analogue: | RGB analogue (0.7/1.0 Vp-p, 75 ohm) |
Digital: | DVI-D (HDCP enabled, TMDS, 100 ohm, DDC/CI) |
TCO’03 and ENERGY STAR standards |
Kensington security port |
VESA FDMI 100mm x 100mm |
Нахил: | -5°/+20° |
