PC: | PC compatible (from VGA up to 2048 x 1536) |
Mac®: | Power Mac™ /G3 from 640 x 480 up to 2048 x 1536 |
Other: | Most workstations |
Фізичні (ШxВxГ): | 500mm (W) x 504.3mm (H) x 526.3mm (D) |
Three-year limited warranty |
Frequency: | Fh:30-127kHz, Fv:50-160Hz |
Video: | RGB analogue (0.7Vp-p, 75 ohms) |
Sync: | H/V separate (TTL), composite, sync-on-green |
Signal: | 15-pin mini D-sub, BNC x 5 [RGBHV] |
Живлення: | 3-pin plug (IEC320) |
Напруга: | AC 90-260 V, 50-60(+/-2)Hz |
Споживання: | 130W (typ) |
Basic: | Power on/off, Menu, up, down, select, Zoom Hotkey |
OnView®: | Contrast, brightness, H/V-position, H/V-size, zoom, pincushion, pin-balance, trapezoid, parallelogram, rotation, top/bottom hooking, linearity centre, linearity edge, H-moiré, H/V-convergence, H/V-focus, corner purity, degauss,ViewMatch® colour, language,ViewMeter®, H/V OSD position, OSD offtime, input select, recall |
Нетто: | 31.1kg |
DDC1, DDC2B, VESA® GTF |
Bandwidth: | 340MHz (typical) |
Meets ENERGY STAR®, VESA® DPMS™, TCO´03, and Energy 2000 standards |
Тип: | 56cm / 22" (20" diagonal viewable area), 90° deflection |
Dot Pitch: | 0.24mm aperture grille uni pitch |
Phosphor: | RGB medium-short persistence B22 |
Glass Surface: | Tint (TM=39.8%), antistatic/antireflection |
0.25mm (max at centre) 0.35mm (max at corner) |
Factory Setting: | 396mm (H) x 297mm (V) |
Maximum Scan: | 400mm (H) x 300mm (V) (Dependent upon signal timing used) |
Вологість: | 5% to 90% (no condensation) |
температура: | 5°C to 35°C (41°F to 95°F) |
