PC: | IBM and PC compatible from VGA up to 1280 x 1024 (non-interlaced) |
Mac®: | Power Mac™ compatible (up to 1024 x 768) |
Фізичні (ШxВxГ): | 405mm (W) x 413mm (H) x 420mm (D) 15.9" (W) x 16.3" (H) x 16.5" (D) |
Three year limited warranty on CRT, parts and labour |
Frequency: | Fh:30~70kHz, Fv:50~120Hz |
Video: | RGB Analogue (Impedance 75 ohms, 0.7Vp-p) |
Sync: | H/V separated (TTL) |
Живлення: | 3-pin plug (IEC320) |
Напруга: | AC 100-240V (auto switch) 50/60 Hz |
Споживання: | 100W (typical) |
OSD: | Brightness, contrast, H/V size, H/V position, zoom, pincushion, pin balance, trapezoid, parallelogram, rotation, ViewMeter®, ViewMatch® colour, degauss, H/V moiré, language, recall |
Physical: | Power ON/OFF, 1, DOWN, UP, 2 |
Температура: | 5°C to 60°C (40°F to 140°F) |
Вологість: | 0% to 95% (non-condensing) |
Нетто: | 17Kgs (37.4lbs) |
DDC1 & DDC2B, VESA® GTF |
Bandwidth: | 110 MHz |
Тип: | 43cm / 17" (16.0" viewable) 90° deflection |
Dot Pitch: | 0.21mm Horizontal, 0.13mm Vertical, 0.25mm Diagonal |
Phosphor: | RGB P22, medium/short persistence |
Glass Surface: | TM=50.0%, Anti-static, anti-reflection |
0.25 mm (max) centre 0.35 mm (max) corner |
Factory Setting: | 310mm (H) x 230mm (V) (typical) |
Maximum Scan: | 320mm (H) x 240 mm (V) [Depending upon signal timing used] |
