PC: | PC and compatibles (from VGA up to 1280 x 1024 non-interlaced) |
Mac®: | Power Mac® |
Фізичні (ШxВxГ): | 410mm (W) x 425mm (H) x 402mm (D) |
Frequency: | Fh: 30 - 70kHz, Fv: 50 - 160Hz |
Video: | RGB Analogue (0.7V/1.0Vp-p, 75 ohms) |
Sync: | H/V separated (TTL), composite |
Живлення: | 3-pin plug (IEC320) |
Signal: | 15 pin mini D-sub, attached cable |
Напруга: | AC 90 - 264V, 50/60Hz (auto switch) |
Споживання: | 75W (typ.), < 2 watt in power save mode |
Basic: | Power on/off, Key 1, Key 2, up, down |
OSD: | Contrast, Brightness, zoom, H/V Size, H/V Position, Pin-balance, Pincushion, Parallel, Trapezoid, Rotation, moiré reduction, degauss, ViewMatch colour adjust (9300K, 6500K, 5000K, User), mode information (ViewMeter), language, memory recall |
температура: | 0°C to 40°C |
Вологість: | 5% to 95% (no condensation) |
Нетто: | 14kg |
Bandwidth: | 120MHz (Typical) |
Meets MPR II |
Тип: | 43cm / 17" (16" diagonal viewable area), 90°deflection |
Dot Pitch: | 0.27mm dot pitch |
Phosphor: | RGB P22 medium/short persistence |
Glass Surface: | Anti-static, anti-glare, AR coat (TM=50%) |
DDC1, DDC2B |
0.25mm (max.) at centre 0.35mm (max.) at corner |
Factory Setting: | 310mm (H) x 230mm (V) (typ.) |
Maximum Scan: | 325mm (H) x 243mm (V) (depending on signal timing used) |
