Black |
Тип: | 65" (64.6" viewable) color TFT active matrix, wide LCD |
Коефіцієнт контрастності: | 5000:1 (typ) 20,000:1 (Dynamic) |
Кути перегляду: | 178º horizontal, 178º vertical |
Яскравість: | 500 cd/m2 (typ) |
Display Area: | 56.2" horizontal x 31.6" vertical; 64.5" diagonal |
Optimum Resolution: | 1920x1080, 600mm dot pitch |
Час відповіді: | 8ms |
Джерело світла: | Long life, 50,000 hrs. (typ) |
Співвідношення сторін: | 16:9 |
Panel Surface: | Anti-glare, hard coating (3H) |
Physical With Stand: | 59.9" x 40.4" x 16.4" / 1522 x 1026 x 417 mm |
Physical Without Stand: | 59.9" x 35.5" x 5.4" / 1522 x 903 x 138 mm |
Packaging: | 64.8" x 41.2" x 11.7" / 1647 x 1046 x 298 mm |
CDP6530-T LCD display, power cable, remote control with batteries, User Guide CD |
Amplifier: | 12-watt / 8 ohm |
Відео вхід: | HDMI, DVI, component, VGA, S-video, CVBS (BNC) |
Video Output: | VGA, component |
Control Input/Output: | RS-232 |
TV/Video comp.: | 480i, 480p, 720p, 1080i, 1080p |
Digital: | HDMI, DVI, S-video YPbPr, CVBS |
Живлення: | 3-pin plug |
Analog: | 15-pin mini D-sub (VGA) |
Напруга: | AC 100–240V (universal), 50–60Hz |
Споживання: | 520W (typ) |
Picture: | Picture mode, contrast, brightness, color temperature, temperature adjust, sharpness |
Front Panel: | Power, Exit, +, –, Menu/Enter |
Special: | Aspect ratio, over scan, power save, image retention, auto adjustment, monitor ID, reset |
Аудіо: | Volume, mute, audio source |
Diagnostic: | Thermal, back light, ambient, 5V detect, 12 detect |
OSD Setting: | Languages, OSD H. position, OSD V. position, OSD timer |
VGA Setting: | Auto adjustment, clock, phase, sharpness, H. position, V. position |
Touch: | Type: Optical Imaging Capability: 2 simultaneous touches Support OS: Windows® 2000, XP, Vista®, Windows 7 (multi-touch requires driver), Max OS X, and Linux (requires evtouch) Touch Resolution: 32,767 x 32,767 Accuracy: +/- 3.5 mm over 95% of touchable area Response Time: 9 ms to 22 ms depending on configuration; 14 ms (typ) Touch Method: Touch with any object, Finger, Pen or Brush Connection: USB Glass: 5mm tempered glass |
Stand (optional), Wall Mount (WMK-013), Wall Mount with Locking Media Player Cradle (WMK-028) |
VESA 200mm x 400mm, 400mm x 400mm |
Брутто: | 189.6 lb. / 86.0 kg |
Нетто: | 156.5 lb. / 71 kg |
Вологість: | 20–90% (non-condensing) |
Temperature (landscape): | 32–104ºF (0–40ºC) |
Temperature (portrait): | 41–95ºF (5–35ºC) |
The lamp in this product contains mercury. Please dispose of in accordance with local, state or federal laws. |
Speakers: | Internal 12-watt (x2) |
640 x 480 at 60 Hz to 75 Hz 800 x 600 at 60 Hz, 60Hz to 75 Hz 1024 x 768 at 60 Hz, 60Hz to 75 Hz 1280 x 768 at 60 Hz, 60Hz to 75 Hz 1360 x 768 at 60 Hz, 60Hz to 75 Hz 1280 x 1024 at 60Hz 1600 x 1200 at 60 Hz 1920 x 1080 at 60Hz (recommended resolution) NTSC, SECAM, 4.43 NTSC Component: 480i,480p,720p,1080i,1080p |
Taiwan |
