ViewSonic VX724 17" LCD Xtreme 3ms ClearMotiv™ Display

LCD

Tip:	43cm / 17" TN-Colour TFT Active Matrix SXGA LCD
Rată de contrast:	135MHz
Unghiuri de vizualizare:	140° horizontal, 130° vertical @ 10:1 160° horizontal, 160° vertical @ 5:1
Luminozitate:	300cd/m² (typ.)
Display Area:	338mm horizontal x 270mm vertical; 43.2cm diagonal
Optimum Resolution:	1280 x 1024
Timp de răspuns:	3ms (grey-to-grey); 5.4ms (on-off-on) (typ.)
Sursă de lumină:	Long life, 40,000hrs. (typ.)
Panel Surface:	Anti-glare
Pixel Pitch:	0,264mm
Colour Support:	16.2M colours (6-bit + 2-bit FRC)
Pixel Clock:	135MHz

COMPATIBILITY

PC: VGA up to 1280 x 1024 (@ max. 75Hz non-interlaced)

Mac®: Power Mac™ G3/G4/G5 1280 x 1024 (@ max. 75Hz)
DIMENSIONS

W x H x D mm: 388 x 438 x 176 (with stand)
388 x 332 x 62 (without stand)
CONȚINUT PACHET

LCD display, power cable, 15-pin VGA video cable, DVI cable,
Quick Start Guide, ViewSonic Wizard CD
WARRANTY

Please see:
www.viewsoniceurope.com/UK/Support/warranty.htm
INPUT

Sync: H/V separated (TTL), composite, sync-on-green

Frequency: Fh: 30-82kHz, Fv: 50-75Hz

Video: RGB analogue (75 ohms, 0.7 Vp-p); DVI-D (TMDS, 100 ohms)
CONNECTOR

Analogue: 15-pin mini D-Sub (detachable cable)

Digital: 24-pin DVI-D (detachable cable)

Putere: 3-pin AC plug, (CEE22)
POWER

Voltaj: AC 100–240V, 50–60Hz (auto switch), internal power supply

Consum: < 32W (typ); ≤ 1 watt in power save mode

CONTROLS

Physical:

Down 5°, Up 20°

Main Menu:

Auto image adjust, brightness, contrast, input select [analogue,
digital], ViewMatch® colour adjust [sRGB, 9300K, 6500K-default,
5400K, user colour - RGB], information [resolution, H. frequency,
V. frequency, pixel clock, model number, serial number], manual
image adjust [H. size, H./V. position, fine tune, sharpness], setup
menu [language (English, French, German, Italian, Spanish, Finnish,
Japanese, Traditional Chinese, Simplified Chinese), resolution
notice, OSD position, OSD timeout, OSD background], memory
recall, OSD lock, power lock

WEIGHT

Masă: 5.0kg (with stand)
POWER MANAGEMENT

Meets TCO’99, Energy and ENERGY STAR standards
ERGONOMICS

Înclinare: Down 5°, Up 20°
OPERATING CONDITIONS

Umiditate: 10% to 90% (non-condensation)

Temperatură: 0°C to 40°C

PC:	VGA up to 1280 x 1024 (@ max. 75Hz non-interlaced)
Mac®:	Power Mac™ G3/G4/G5 1280 x 1024 (@ max. 75Hz)

Sync:	H/V separated (TTL), composite, sync-on-green
Frequency:	Fh: 30-82kHz, Fv: 50-75Hz
Video:	RGB analogue (75 ohms, 0.7 Vp-p); DVI-D (TMDS, 100 ohms)

Analogue:	15-pin mini D-Sub (detachable cable)
Digital:	24-pin DVI-D (detachable cable)
Putere:	3-pin AC plug, (CEE22)

Voltaj:	AC 100–240V, 50–60Hz (auto switch), internal power supply
Consum:	< 32W (typ); ≤ 1 watt in power save mode

Umiditate:	10% to 90% (non-condensation)
Temperatură:	0°C to 40°C
