CDX4652-L
Descrierea produsului
The ViewSonic CDX4652-L is a 46” (46’’ viewable) commercial LED display that features an ultra-narrow bezel less than 3mm wide. With an edge-to-edge width of only 5.6mm between combined displays, the CDX4652-L is perfect for digital signage and video wall applications that deliver seamless, high-impact messaging in commercial, hospitality, and transportation venues. With its Full HD 1080p resolution, 500-nit brightness, 3,500:1 high contrast ratio, SuperClear® image enhance technology and wide viewing angles, as well as dual 10W stereo speakers, the CDX4652-L delivers sharp, vivid images with incredible sound for superior multimedia performance. Integrated DVI-out and RS232-out ports, along with a RS232 pass-through function, support the installation, management and scheduling of video wall for up to 5x5 daisy-chained displays. In addition, versatile connectivity options including HDMI, DisplayPort, DVI, D-Sub, YPbPr, and CVBS inputs, offer convenient, one-time installation for a variety of high-definition devices. The ViewSonic CDX4652-L is a reliable and easy-to-maintain commercial display solution.
Vizitează Noi
  • www.viewsonic.com
  • LCD PANEL
    Dimensiune Panel: 46''
    Tipul/ Tehnologia: TFT LCD Module with DLED Backlight
    Suprafață Display (mm): 1018.08(H) x 572.67 (V)
    Aspect Ratio: 16:9
    Rezoluție: 1920x1080
    Colors: 16.7M
    Luminozitate: 500 nits (typ.)
    Rată de contrast: 3500:1 Typ
    Timp de răspuns: 8ms
    Unghiuri de vizualizare: H = 178, V = 178 typ.
    Backlight: LED
    Durată de viață sursă de lumină fundal: 50,000 Hours Typ
    Hardness: Haze 44% /3H (Anti-Glare)
  • INPUT
    HDMI: x1
    RGB/ VGA: x1
    Display Port: x1
    DVI: x1
    Audio: x1
    CVBS: x1
    YPbPr: x1
    IR Pass Through: x1
    RS232: x1
  • OUTPUT
    DVI: x1
    Audio: x1
    Difuzor: x1
    IR Pass Through: x1
    RS232: x1
  • LAN
    RJ45: x1
  • DIFUZOARE
    10 Wx2
  • COMPATIBILITY
    RGB PC/ HDMI PC: Refer to timing table
    CVBS: 480i
    YPbPr: 480i, 480p,720p,1080i,1080p
    HDMI: 480i, 480p,720p,1080i,1080p
  • CONTROLS
    Physical- Top OSD: PICTURE: POWER, MUTE, INPUT, VOL -/+, UP, DOWN, MENU SCREEN: Brightness, Contrast, Sharpness,Black Level, Tint, Color, Color Temperature, Gamma Selection, Noise Reduction, Film Mode, Picture Reset Auto Setup, Auto Adjust, H Position, V Position, Clock, Clock Phase, Zoom Mode, Custom Zoom, Input Resolution, Screen Reset SOUND: Balance, Treble, Bass, Audio Reset PIP: PIP Mode, PIP Size, PIP Audio, PIP H Position, PIP V Position, SUB Input, PIP Reset CONFIGURATION 1: Off Timer, Schedule, Data and Time, Configuration 1 Reset CONFIGURATION 2: Language, OSD Turn Off, OSD H Position, OSD V Position, Information OSD, Monitor Information, Monitor ID, IR Control, Tiling, Power on Delay, Closed Caption, Configuration 2 Reset. CONFIGURATION 3: Power Save, Heat Status, Screen Saver, Side Border Color, Configuration 3 Reset ADVANCED OPTION: Input Change, Terminal Setting, Scan Conversion, Color System, Scan Mode, Serial Control, Lan Setting, APM, Advanced Option Reset, Factory Reset
  • POWER
    Voltaj: 100-240 VAC +/- 10% Wide Range, 50-60Hz +/-3 Hz
    Consum: Normal 120W, Max 200W ("On") < 0.5 W ("Off")
  • ERGONOMICS
    Wall Mount (VESA® ): 400x200 mm, 200x200 mm
  • OPERATING CONDITIONS
    Temperature (º C): 0°C to 40°C
    Umiditate: 20% ~ 80% non-condensing
  • DIMENSIONS (W X H X D)
    Dimensiuni (inch/ mm): 40.31 x 24.78 x 15.75 / 1023.98 x 629.41 x 400 (w/ stand);
    40.31 x 22.7 x 4.95 / 1023.98 x 578.57 x 125.7 (w/o stand)
    Ambalare (inch/ mm): 50.79 x 34.45 x 14.29 / 1290 x 875 x 363
  • WEIGHT
    Masă (Ib/ kg): 55.78 / 25.3 (w/ stand); 50.71 / 23 (w/o stand)
    Greutate (Ib/ kg): 70.33 / 31.9
  • WARRANTY
    **Warranty offered may differ from market to market
  • WHAT'S IN THE BOX?
    1. CDX4652-L LCD Monitor
    2. Remote Control with batteries
    3. User manual CD wizard
    4. Quick Start Guide
    5. Power Cables (UK, EU)
    6. VGA cable
    7. RS232
    *Actual content may differ from market to market
