ViewSonic VNB101 Thin, Stylish, yet Amazingly Capable.

COLORS

Black
DIMENSIONS

W x H x D mm: 266 X 25 X 182
ZAWARTOść OPAKOWANIA

ViewSonic NetBook VNB101

Power adapter

Power cords

Quick Start Guide
AUDIO

Głośnik: Built-in 2 x 1-watt stereo speakers

Microphone: Built-in microphone

INPUT

Keyboard:	Built-in 92%-size keyboard with 84 keys, including 12 function keys and 4 arrow keys
Trackpad:	Multi-touch trackpad, supports two-finger scrolling, pinch, rotate, swipe, tap, double-tap, and drag capabilities

CONNECTOR

Network:	10/100Base-T Ethernet
Video Output:	Support 15-pin D-Sub VGA output
Audio (input/output):	Audio line in Audio line out
USB:	2 USB 2.0 ports (1 on right and 1 on left, up to 480Mbps)
Card Reader:	5-in-1 card reader supports Secure Digital (SD), Secure Digital High Capacity (SDHC), MultiMediaCard (MMC), Memory Stick (MS), Mmeory Stick Pro (MS Pro)
Lock Slot:	Kensington® lock slot

POWER

Napięcie: AC 100 - 240V; DC 12V

AC Adapter: 36W (max.) output

Battery: 3400mAh Li-polymer rechargeable battery, 7.4V DC.
OPERATING CONDITIONS

Temperatura: 5°C - 35°C

Wilgotność powietrza: 35% - 85%

Storage Temperature: -20°C - 55°C

Storage Humidity: 20% - 93%
WEIGHT

Waga: 1.1kg
MEMORY

RAM: 1GB DDRII 667MHz

Cache: On-die, primary 32-kB instructions cache and 24-kB, write-back data cache; 512-kB on-die second level cache
NETWORKING

Wireless: Built-in IEEE 802.11b/g Wi-Fi wireless networking

Ethernet LAN: Built-in 10/100BASE-T Ethernet (RJ-45 connector)

Bluetooth: Buil-in Bluetooth 2.1 + EDR (Enhanced Data Rate
DISPLAY

Proporcje obrazu: 16:9

Rozdzielczość Natywna: 1024x600 (WSVGA)

Wyświetlacz: 25 cm / 10" (diagonal) TFT LED backlit widescreen
WEBCAM

300,000-pixel webcam
CORE

CPU: Intel Atom® N280 (1.66GHz, 667MHz FSB)
GRAPHICS

Procesor: Intel® GMA950 graphics processor with 128MB (max.) shared with main memory
STORAGE

HDD: 160GB Serial ATA (SATA) hard drive

SOFTWARE

OS:	Geniune Microsoft® Windows® XP Home Edition Service Pack 3
Bundled software:	Linpus Quick OS instant-on Linux, includes: Internet browser - FireFox Instanat messenger - Pidgin, supports MSN Messenger, Yahoo! Messenger, ICQ, AIM instant messaging protocols Voice over Internet Protocol - Skype

Głośnik:	Built-in 2 x 1-watt stereo speakers
Microphone:	Built-in microphone

Napięcie:	AC 100 - 240V; DC 12V
AC Adapter:	36W (max.) output
Battery:	3400mAh Li-polymer rechargeable battery, 7.4V DC.

RAM:	1GB DDRII 667MHz
Cache:	On-die, primary 32-kB instructions cache and 24-kB, write-back data cache; 512-kB on-die second level cache

Wireless:	Built-in IEEE 802.11b/g Wi-Fi wireless networking
Ethernet LAN:	Built-in 10/100BASE-T Ethernet (RJ-45 connector)
Bluetooth:	Buil-in Bluetooth 2.1 + EDR (Enhanced Data Rate

Proporcje obrazu:	16:9
Rozdzielczość Natywna:	1024x600 (WSVGA)
Wyświetlacz:	25 cm / 10" (diagonal) TFT LED backlit widescreen
