UMB202

TeamJoin™ 4K Video Bar System

Sony 4K Ultra HD camera sensor for advanced image processing
Intelligent auto framing and DOA voice tracking technology
6-mic array beamforming soundbar with an 11W speaker

Sales Enquiry

GALLERY

OVERVIEW

The UMB202 TeamJoin™ 4K Video Bar System is part of the ViewSonic TeamJoin™ solutions for Microsoft Teams Rooms, optimizing collaboration in meeting rooms of diverse sizes. Boasting a 4K Sony camera sensor, 5x digital zoom, auto-framing, and DOA voice tracking, it delivers a premium visual experience. Complemented by six beamforming microphones, which cover an expansive 8-meter range, and an 11W speaker, the camera ensures crystal-clear audiovisual quality for seamless communication.

From Boardroom to Every Room. Videoconferencing for All.

Elevate Your Presence in Every Interaction

The UMB202 TeamJoin 4K Video Bar System's intelligent auto-framing and Direction-of-Arrival (DOA) voice tracking technology accurately detect individuals and their voices, while the 5x digital zoom with electronic pan and tilt ensures your presence is felt in every interaction, fostering inclusivity and collaboration in every meeting.

See and Hear Everyone Clearly

Ensure everyone is seen and heard with the UMB202 TeamJoin 4K Video Bar System, equipped with a built-in 6-microphone array, an 8W+3W front-facing speaker, and an Ultra HD 4K camera featuring an advanced Sony sensor..

Dimension & I/O Ports

K-Slot
Mic Mute
Audio Out
DC in
C-type USB Port
Power input via RJ45

Bundles

TeamJoin™ TRS10-UB

Computing Engine, Touch Console and Video Bar System for Microsoft Teams Rooms

Learn More

SPECIFICATIONS

Camera
Resolution: H.264/MJ: @30FPS
(1)3840×2160 (2)2560×1440
(3)1920×1080 (4)1280×720
(5)1024×576 (6)960×540
(7)800×600 (8)640×480
(9)640×360 (10)480×270
(11)352×288 (12)320×240
NV12 / YUY2: @30FPS
（1）1920×1080（2）1280×720
（3）640×360
Sensor: IMX577 1/2.3 inch, CMOS, 12M pixel
FOV: 117.8° (DFOV) ，109° (HFOV)，74.4° (VFOV)
PTZ: EPTZ (5X digital Zoom)
Digital Noise Reduction: Yes
White Balance: Yes
Exposure: Yes
Audio
Microphone array: 6 element, 8 meters pickup range
Speaker: mid-bass modulex1, treble module x1 in one box
(Maximum output 8W + 3W)
Output Power: 80 dBA @ 1000 Hz @ 1 meter at maximum volume
I/O
USB-TypeC: 1
Audio Out: 1
DC 2.0 Power: 1
RJ45: 1 (Only for power supply)
IEEE 802.3 at，25.50W (max)
Power Button: Power Button: In startup mode, press the power button to mute.
In standby mode, press the power button to power on.
MIC Mute Button: Yes

USB feature
Connection type: USB 3.0, downward compatible with USB2.0
Video Compression: MJPEG /YUY2 / H.264 / NV12
USB audio: 16K sampling rate, support UAC2.0
USB video communication protocol: UVC 1.1
UVC PTZ control: Support (Control Via Remote controller)
Intelligent Function
Auto Framing: Yes
Voice tracking: Yes
System Compatibility
OS: Windows 7 /8.1/10/11 or higher
macOS® 10.10 or higher
Google ChromebookTM Version 29.0.1547.70 or higher
Android
Accessory (inbox)
USB Type-C cable: 1.8m typeC x1
(include TypeC to A Plug adaptor)
Remote Control: Yes
Power adapter: 1
Wall mount components: 1
Screws: Yes
Lens Cover: 1
QSG: Yes
Compliance statement: Yes
