상업용 디스플레이
CDE5010
주요 기능
- 50" screen with 3840 x 2160 resolution
- Built-in browser for displaying internet content
- ViewBoard® Cast content sharing software (Optional)
- vController software for remote display management
- USB multimedia player for video, photo, and music playback
제품 설명
The ViewSonic® CDE5010 is a 50" (50" viewable) 4K Ultra HD commercial display purpose-built to deliver eye-catching imagery for hotels, restaurants, retail, business, and more. With stunning 3840x2160 resolution, 350-nit high brightness, wide viewing angles, and dual 10W speakers this display provides immersive, high-impact messaging wherever needed. In addition to HDMI, DVI, and VGA inputs to connect with various high definition devices, this display utilises an integrated multi-core processor and 8GB of internal memory, allowing customers to playback multimedia content via USB without the need for a PC. To make life even easier, the bundled vController software offers easy maintenance and intuitive interfaces for remote management via a PC server or laptop. Flicker-Free and Blue Light Filter technologies help provide a comfortable viewing environment.
방문
- www.viewsonic.com
-
표시
패널 크기: 50" 유형/기술: TFT LCD Module with LED Backlight 표시면적(mm): 1095.84 (H) x 616.4 (V) 가로 세로 비율: 16:9 Colors: 1.07B colours 밝기: 350 nits (typ.) 대비 비율: 4000:1 (typ.) 응답 시간: 8 ms 보기 각도: H = 178, V = 178 (typ.) 백라이트 라이프: 30,000 Hours 표면 처리: Anti-Glare,3H (Haze=2%) 베젤: Slim 오리엔테이션: Landscape -
INPUT
HDMI: x2 RGB / VGA: x1 DVI: x1 오디오: x1 PC audio(3.5mm) RS-232: x1 IR 패스스루: x1 SD/SDHC: x1 (Micro SD) -
OUTPUT
오디오: x1 (RCA) RS232: x1 IR 패스스루: x1 -
LAN
RJ45: x1 -
USB
A형: 2.0 Type A : x 1 (USB Playback), 3.0 Type A : x 1 (USB Playback) -
스피커
10W x 2 -
COMPATIBILITY
RGB PC/HDMI PC: Up to 1920x1080 @60Hz. Refer to timing table (RGB PC) HDMI: 480i, 480p,720p,1080i,1080p, 4K2K@60Hz DVI: 480i, 480p,720p,1080i,1080p 안드로이드 버전: Android 5.0.1 -
POWER
전압: 100-240 VAC +/- 10% Wide Range 소비.: Normal 140 W, Max 175 W -
ERGONOMICS
벽면 장착(VESA® ): 400x400 mm -
OPERATING CONDITIONS
온도(θ C): 5 to 40°C 습도: 20% ~ 80% -
치수(가로 X 세로 X 세로)
물리적(인치/mm): 44.24 x 25.46 x 2.67 in/1123.6 x 646.7 x 67.8 mm 포장(inch/mm): 50.47 x 33.27 x 7.99 in/1282 x 845 x 203 mm -
WEIGHT
순(lb/kg): 13 kg / 28.66 lbs (w/o stand); 14.9 kg / 32.85 lbs (with Stand) 총중량(파운드/kg): 16.5 kg / 36.38 lbs -
패키지 내용물
1. CDE5010 commercial display
2. Remote Control with batteries
3. User manual CD wizard
4. Quick Start Guide
5. Power Cables
6. RS232 cable
7. RS232 daisy chain cable (2.5mm – 2.5mm)
8. IR sensor cable
