OVERVIEW
The ViewSonic® WPG-370 Full HD 1080p wireless presentation gateway allows users to wirelessly stream HD content from laptops and other mobile devices to projectors, televisions and digital signages. The WPG-370 is also designed to work with a mobile app that enables content to be streamed directly from smart phones and tablets through the gateway. For business users, the WPG-370 provides user friendly PC-less media streaming. Content can be streamed from a USB drive through the WPG-370 without a PC. The WPG-370 is designed to be flexible and convenient, which makes it the perfect wireless presentation solution for projectors and also a superior advertisement solution for digital signage. Plus, the WPG-370 offers 2.4GHz and 5GHz dual band wireless transmission for smoothly multimedia content streaming, especially 1080p videos. It will intelligent select appropriate band in different usage scenarios. The WPG-370 presentation gateway will give you a perfect wireless transmission performance each time.
WiDi Technology for Full HD 1080p Wireless Video Streaming
With the latest Intel® WiDi® technology, the WPG-370 works seamlessly with WiDi® laptops to deliver Full HD 1080p content, as well as digital 5.1 channel audio, over a wireless connection. Presenters can deliver engaging, high-definition presentations without needing a physical HDMI cable.
Mobile App for Smart Phones & Tablets
As a wireless connected gateway, the WPG-370 supports a wide range of mobile-device apps from Google Play and the Apple App Store. This offers presenters the flexibility to wirelessly connect their smart phones and tablets to any projector, television, or digital signage via the WPG-370. Content such as videos and photos can also be streamed from Android or iOS devices. This gateway brings a quick and simple presentation option for on-the-go presenters as well as an immediate sharing option for family and friends.
Support Wireless Content Sharing on Your TV
Now with HDMI connectivity for your TV, you can stream Full HD 1080p video and graphic-rich gaming wirelessly from WiDi® laptops, smartphones or tablets. You now have the freedom to create great memories by sharing you greatest moments with your family and friends.
Support wireless content sharing on large-format display
Easy and safe, the WPG-370 wireless connectivity allows advertising agencies to remotely manage content displayed on digital signage in public areas. This means that contents can be updated in a timely manner without having to open protective digital signage cases to access a diplay’s I/O port. Now, by using a laptop, smart phone or tablet, anyone can complete the task wirelessly with just a few clicks.
Versatile connectivity: HDMI, VGA, and USB
Various connection options are supported, including HDMI to provide the highest picture and sound quality possible without degradation, and Intel WiDi® technology to wirelessly stream Full HD 1080p video and true digital audio. VGA connections are also available for plugging in a regular display or projector. And with its PC-less presentation feature, videos or images from a USB flash drive can be displayed without having to wait for a PC to boot up.
Full Networking Capability
Equipped with LAN port, this device offers full networking capability that allows you to remotely monitor and manage it over a network connection. In addition, mobile users can connect to the WPG-370 wirelessly in order to present materials via projector to audiences wherever there is an Internet connection.
App - ViewMedia
Support ViewSonic® WPG-370 to provide real-time multi-media share
With the ViewMedia App, even mobile devices can broadcast images, music, and movies on the project wirelessly. Projector network connectivity saves everybody time by enabling the content share from multiple devices, making users set-ups smoother and more efficient.
SPECIFICATIONS
- KEY COMPONENTHDMI Resolution: 1080p, 720p, 480p
VGA Resolution: 800x600, 1024x768 (default), 1280x800, 1280x1024, 1366x768
Operation Mode: Presentation (for PC & Mac)
WiDi (for WiDi laptops)
Media Streaming (for Android & iOS devices w/ iMediaShare app) - WIRELESS NETWORKBand Frequency: 2.4GHz / 5GHz Dual Band
802.11a: 54/48/32/24/12/9/6 Mbps
802.11b: 11/5.5/2/1 Mbps
802.11g: 54/48/36/24/12/9/6 Mbps
802.11n (20MHz): MCS0-7, up to 72Mbps
802.11n (40MHz): MCS0-7, up to 150Mbps - WIRELESS ENCRYPTIONWEP 64/128, WPA/WPA2, WPA-PSK, WPA2-PSK
- CONNECTORVideo Output Analog: DB-15
Video Output Digital: HDMI 1.3 w/ HDCP
Audio Output: R/L RCA, SPDIF
LAN: RJ45
Wireless: 802.11a/b/g/n 2.4GHz / 5GHz
USB: Type A (PC-Less Slideshows) - OS compatibilityPC: Windows 7 & 8 for 32bits &64bits
MAC: MAC OS 10.7 and above - POWERVoltage: AC 100–240V (universal), 50 / 60Hz, 5V/1A output
Consumption: 5W (typ.) - CONTROLSButtons: Power (top panel), Mode (side)
Remote: Web-based interface (192.168.59.254/remote)
OSD: Network, Audio, Video, System
(See user guide for full OSD functionality) - OPERATING CONDITIONSTemperature: 23–113º F (-5–45º C)
Humidity: 0–95% (non-condensing)
Altitude: 0~13,123 ft (4,000m) - DIMENSIONS (W x H x D)Physical: 191.5 x 102.6 x 32.2 mm / 57.54 x 4.04 x 1.27 in.
- WEIGHTNet: 0.5 lb. / 0.2 kg
Gross: 1.9 lb. / 0.8 kg - REGULATIONSSafety/EMC: FCC-B, CE, ErP, RoHS
Wi-Fi: FCC-ID, CE, R&TTE, NCC, EAC - Package ContentViewSync WPG-370 Wireless Presentation Gateway, universal power adapter, Quick Start Guide, ViewSonic Wizard CD
