ViewSonic VX912 19" XTREME LCD MONITOR WITH 5MS ULTRA-FAST RESPONSE TIME

LCD

Típus:	48cm / 19" TN colour TFT active matrix SXGA LCD
Kontrasztarány:	700:1 (typ.)
Betekintési szögek:	150° horizontal, 135° vertical (at 10:1) 170° horizontal, 155° vertical (at 5:1)
Fényerő:	300cd/m²
Display Area:	37.6cm horizontal x 30.1cm vertical, 48.3cm diagonal
Optimum Resolution:	1280 x 1024
Válaszidő:	5ms (off-on-off) (typ.)
Panel Surface:	Anti-glare (3H)
Pixel Pitch:	37.6cm horizontal x 30.1cm vertical, 48.3cm diagonal
Colour Support:	16.2M colours (6-bit+2-bit FRC)
Pixel Clock:	135MHz

COMPATIBILITY

PC: VGA up to 1280 x 1024 non-interlaced (max. 75Hz)

Mac®: Power Mac™ up to 1280 x 1024 non-interlaced (max. 75Hz)
DIMENSIONS

W x H x D mm: 431 x 468 x 201 (with stand)
431 x 370 x 66 (without stand)
CSOMAG TARTALMA

LCD Monitor, power cable, 15-pin VGA video cable, audio cable, Quick Start
Guide, ViewSonic Wizard CD-ROM (User Guide/drivers)
WARRANTY

Please see: www.viewsoniceurope.com/UK/Support/warranty.htm
INPUT

Sync: H/V separate (TTL), composite, sync on green

Digital: DVI-D (TMDS, 100 ohm)

Analogue: RGB analogue (0.7 Vp-p, 75 ohm)

Frequency: Fh: 30 – 82kHz, Fv: 50 – 85Hz
CONNECTOR

Analogue: 15-pin mini D-Sub (detachable cable)

Digital: 24-pin DVI-D (detachable cable)

Audió: 3.5mm stereo audio line-in

Teljesítmény: 3-pin (CEE22)
POWER

Feszültség: AC 100 – 240V, 50/60Hz (auto switch), internal power supply

Fogyasztás: 35 watt (typ.), <1 watt in power save mode

CONTROLS

Basic:	Power on/off, menu [1], up, down, select [2]
OSD:	Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number, website), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall

OPERATING CONDITIONS

Hőmérséklet: 0°C to 40°C

Páratartalom: 10% to 90% (non-condensation)
WEIGHT

Net: 6.7kg (with stand), 5.3kg (without stand)
POWER MANAGEMENT

Meets TCO’99 and ENERGY standards
ERGONOMICS

35 watt (typ.), <1 watt in power save mode
SECURITY

Kensington® security port
VESA MOUNT COMPLIANT

VESA FDMI 100mm x 100mm
AUDIO

Speakers: 2 x 1 watt

PC:	VGA up to 1280 x 1024 non-interlaced (max. 75Hz)
Mac®:	Power Mac™ up to 1280 x 1024 non-interlaced (max. 75Hz)

Sync:	H/V separate (TTL), composite, sync on green
Digital:	DVI-D (TMDS, 100 ohm)
Analogue:	RGB analogue (0.7 Vp-p, 75 ohm)
Frequency:	Fh: 30 – 82kHz, Fv: 50 – 85Hz

Analogue:	15-pin mini D-Sub (detachable cable)
Digital:	24-pin DVI-D (detachable cable)
Audió:	3.5mm stereo audio line-in
Teljesítmény:	3-pin (CEE22)

Feszültség:	AC 100 – 240V, 50/60Hz (auto switch), internal power supply
Fogyasztás:	35 watt (typ.), <1 watt in power save mode

Hőmérséklet:	0°C to 40°C
Páratartalom:	10% to 90% (non-condensation)
