Típus: | 43cm / 17" colour TFT active matrix SXGA LCD |
Kontrasztarány: | 450:1 (typ) |
Betekintési szögek: | 150° h, 125° v (at 10:1), 160° h, 145° v (at 5:1) |
Display Area: | 33.8cm horizontal x 27.0cm vertical, 43.2cm diagonal |
Optimum Resolution: | 1280x1024 |
Válaszidő: | 16 ms (typ) |
Panel Surface: | Anti-glare |
Fényerő: | 270 cd/m² (typ) |
PC: | PC compatible from VGA to 1280x1024 |
Mac®: | Power Mac™ (up to 1280x1024) |
W x H x D mm: | 502 x 405 x 195 (with stand), 502 x 340 x 63 (without stand) |
Please see: http://www.viewsoniceurope.com/UK/Support/warranty.htm |
Hangszóró: | 2 x 5 watts |
Amplifier: | 5 watts at 1kHz |
Sync: | H/V separated (TTL), composite, sync on green |
Analogue: | RGB analogue (0.7 Vp-p, 75 ohms) |
Digital: | DVI-D (TMDS, 100 ohms) |
Frequency: | Fh: 30-82 kHz, Fv: 50-85 Hz |
Audio (input/output): | 3.5mm stereo connector (line-in)/(line-out) |
Headphone: | 3.5mm stereo connector |
Signal: | RGB (15-pin mini D-sub), DVI-D, detachable cable |
Teljesítmény: | 3-pin plug (IEC) to External brick, 12 volt DC to Head |
Feszültség: | AC 100-240 V (50/60Hz), auto switch |
Fogyasztás: | 50 watts (max.) |
OSD: | Auto image adjust, contrast, brightness, input select, colour adjust (sRGB, 9300K, 6500K [default], 5400K, user RGB), information (mode, model number, serial number, website), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), memory recall |
Physical: | Power (soft), 1, menu up, down, 2, (enter) input select, volume +/- |
Hőmérséklet: | 0°C to 40°C |
Páratartalom: | 10% to 90% (non-condensation) |
Net: | 5.6 kg |
TCO’99, ENERGY Standards |
