Típus: | 22” Wide TN colour TFT active matrix WSXGA+ LCD |
Kontrasztarány: | 1000:1 with 4000:1 DCR |
Betekintési szögek: | 170° horizontal, 160° vertical (at 10:1) 170° horizontal, 170° vertical (at 5:1) |
Fényerő: | 300cd/m² |
Display Area: | 47.4cm horizontal x 29.6cm vertical; 55.9cm diagonal |
Optimum Resolution: | 1680 x 1050@60Hz |
Válaszidő: | 3ms (grey-to-grey), 5ms (off-on-off, typ.) |
Fényforrás: | Long life, 40000 hrs. (min.) |
Panel Surface: | Anti-glare (3H) |
Pixel Pitch: | 0.282mm |
Colour Support: | 16.7M colours supported (6-bit+2-bit FRC) |
Pixel Clock: | 165MHz |
PC: | VGA up to 1680 x 1050 non-interlaced |
Mac®: | Power Mac™ up to 1680 x 1050 non-interlaced |
Physical With Stand: | 527 x 450-530 x 225 |
Physical Without Stand: | 527 x 366 x 60 |
W x H x D mm: | 575 x 525 x 270 |
LCD Monitor, power cable, 15-pin VGA video cable, DVI cable, audio cable, USB cable, Quick Start Guide, webcam CD-ROM, ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language) |
Hangszóró: | 2 x 2 watt integrated invisible stereo speakers |
Microphone: | Integrated into bezel |
Analogue: | 15-pin mini D-Sub (detachable cable) |
Digital: | 24-pin DVI-D (detachable cable) (HDCP enabled) |
Teljesítmény: | 3-pin AC plug (CEE22) |
USB: | 1 x upstream USB 2.0 (for webcam) |
Feszültség: | AC 100–240V, 50/60Hz (auto switch), internal power supply |
Fogyasztás: | 45 watt (typ.), <2 watt in power save mode |
Basic: | Power, menu [1], up, down, select [2] |
OSD: | Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), View-Match® colour adjust (sRGB, 9300K, 7500K, 6500K, 5400K, user RGB), audio adjust (volume, mute), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), auto white balance, OSD/power lock, memory recall |
Hőmérséklet: | 0°C–40°C |
Páratartalom: | 10%–90% (non-condensation) |
Net With Stand: | 5.9kg |
Net Without Stand: | 4.6kg |
Bruttó: | 8.4kg |
Frequency: | Fh: 24–82kHz, Fv: 50–85Hz |
Sync: | H/V separate (TTL), composite, sync on green |
Analogue: | RGB analogue (0.7/1.0 Vp-p, 75 ohm) |
Digital: | DVI-D (HDCP enabled, TMDS, 100 ohm) |
Meets MPR II and ENERGY standards |
Kensington security port |
VESA FDMI 100mm x 100mm |
Dönthető: | Down 5°, Up 20° |
Forgatható: | 360° (180° left/right) |
Height Adjustment: | 0~80mm |
1.3M integrated into bezel |
