Black |
Típus: | 56 cm / 22"Wide TN colour TFT active matrix WSXGA+ LCD |
Kontrasztarány: | 1000:1 (typ.), 12000:1 DCR (typ.) |
Betekintési szögek: | 170° horizontal, 160° vertical (at 10:1) 170° horizontal, 170° vertical (at 5:1) |
Fényerő: | 250cd/m² (typ.) |
Display Area: | 47.4cm horizontal x 29.6cm vertical, 55.9cm diagonal |
Optimum Resolution: | 1680 x 1050@60Hz |
Válaszidő: | 5ms (off-on-off) (typ.) |
Fényforrás: | LED backlight array |
Panel Surface: | Anti-glare (3H) |
Pixel Pitch: | 0.282mm |
Colour Support: | 16.7M colours supported (6-bit+2-bit FRC) |
Pixel Clock: | 170MHz |
Színskála: | Wide colour gamut: 118% NTSC |
PC: | VGA up to 1680 x 1050 non-interlaced |
Mac®: | Power Mac™ up to 1680 x 1050 non-interlaced |
Physical With Stand: | 524 x 482 x 244 |
Physical Without Stand: | 524 x 355 x 64 |
W x H x D mm: | 575 x 522 x 150 |
LCD Monitor, power cable, 15-pin VGA video cable, DVI cable, audio cable, Quick Start Guide, ViewSonic Wizard CD-ROM (multi-language User Guides/drivers and SRS WOW HD software) |
Hangszóró: | 2 x 2.5 watt integrated stereo speakers with SRS WOW HD |
Analogue: | 15-pin mini D-Sub (detachable cable) |
Digital: | 24-pin DVI-D (detachable cable) (HDCP enabled) |
Teljesítmény: | 3-pin AC plug (CEE22) |
Audió: | 3.5mm stereo audio line-in |
Feszültség: | AC 100–240 V, 50–60 Hz (auto switch), internal power supply |
Fogyasztás: | 36 watt (typ.), <1 watt in power save mode |
Basic: | Power, menu [1], select [2], up, down |
OSD: | Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), Audio adjust (volume, mute), ViewMatch® colour adjust (sRGB, 9300K, 7500K, 6500K, 5000K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language [11 options], resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall |
Hőmérséklet: | 5°C – 35°C |
Páratartalom: | 20% – 80% (non-condensation) |
Net With Stand: | 6.0kg |
Net Without Stand: | 4.8kg |
Packaging: | 7.5kg |
Frequency: | Fh: 30–82kHz, Fv: 50–75Hz |
Sync: | H/V separate (TTL), composite, sync on green |
Analogue: | RGB analogue (0.7/1.0 Vp-p, 75 ohm, DDC/CI) |
Digital: | DVI-D (HDCP enabled, TMDS, 100 ohm, DDC/CI) |
Meets ENERGY STAR standards |
Kensington® security port |
VESA FDMI 100mm x 100mm |
Dönthető: | Down 5°, Up 17° |
