Típus: | 19” TN colour TFT active matrix SXGA LCD |
Kontrasztarány: | 700:1 (typ.) |
Betekintési szögek: | 150° horizontal, 135° vertical (at 10:1) 160° horizontal, 155° vertical (at 5:1) |
Display Area: | 37.6cm horizontal x 30.1cm vertical; 48.3cm diagonal |
Optimum Resolution: | 1280 x 1024@60Hz |
Válaszidő: | 8ms (off-on-off) (typ.) |
Fényforrás: | Long life, 50000 hrs. (min.) |
Panel Surface: | Anti-glare (3H) |
Pixel Pitch: | 0.294mm |
Colour Support: | 16.2M colours (6-bit+2-bit FRC) |
Pixel Clock: | 135MHz |
Fényerő: | 300cd/m2 |
Mac®: | Power MacTM up to 1280 x 1024 non-interlaced |
PC: | VGA up to 1280 x 1024 non-interlaced |
W x H x D mm: | 426 x 457 x 205 (physical with stand) 426 x 397 x 64 (physical without stand) 497 x 512 x 158 (packaging) |
LCD Monitor, power cable, D-sub video cable, audio cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) (multi-language) |
Analogue: | 15-pin mini D-Sub (detachable cable) |
Audió: | 3.5mm stereo audio line-in |
Teljesítmény: | 3-pin AC plug (CEE22) |
Feszültség: | AC 100–240V, 50/60Hz (auto switch), internal power supply |
Fogyasztás: | 39 watt (typ.), <1 watt in power save mode |
Basic: | Power, menu [1], up, down, select [2], mute |
OSD: | Auto image adjust, contrast, brightness, input select (D-sub, audio (volume, mute), ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall |
Hőmérséklet: | 5°C–35°C |
Páratartalom: | 20%–80% (non-condensation) |
Net: | 5.2kg (with stand) 4.3kg (without stand) |
Bruttó: | 6.8kg (with stand) |
Frequency: | Fh: 30–82kHz, Fv: 56–76Hz |
Analogue: | RGB analogue (0.7/1.0 Vp-p, 75 ohm) |
Sync: | H/V separate (TTL) |
Meets TCO’03 and ENERGY STAR® standards |
Kensington® security port |
VESA FDMI 100mm x 100mm |
Dönthető: | Down 5°, Up 20° (90° for wall mount) |
Speakers: | 2 x 1.5 watt integrated stereo speakers |
