Típus: | 48cm / 19" TN colour TFT active matrix SXGA LCD |
Kontrasztarány: | 400:1 (typ.) |
Betekintési szögek: | 150° horizontal, 130° vertical (at 10:1) 160° horizontal, 150° vertical (at 5:1) |
Fényerő: | 280cd/m² (typ.) |
Display Area: | 37.6cm horizontal x 30.1cm vertical; 48.3cm diagonal |
Optimum Resolution: | 1280 x 1024 |
Válaszidő: | 8ms (off-on-off) (typ.) |
Fényforrás: | Long life, 50000 hrs. (typ.) |
Panel Surface: | Anti-glare (3H) |
Pixel Pitch: | 0.294mm |
Colour Support: | 16.2M colours (6-bit+2-bit FRC) |
Pixel Clock: | 135MHz |
PC: | VGA up to 1280 x 1024 non-interlaced (max. 75Hz) |
Mac®: | Power Mac™ up to 1280 x 1024 non-interlaced (max. 75Hz) |
Physical With Stand: | 423 x 434 – 534 x 221 (with stand) |
Physical Without Stand: | 423 x 381 x 52 (without stand) |
LCD monitor, power cable, VGA cable, audio cable, Quick Start Guide, ViewSonic Wizard CD (User Guide/drivers) |
Hangszóró: | 2 x 1-watt |
Amplifier: | 1-watt @ THD < 8% |
Analogue: | 15-pin mini D-Sub (attached cable) |
Audió: | 3.5mm stereo audio line-in |
Teljesítmény: | 3-pin AC plug (CEE22) |
Feszültség: | AC 100 – 240V, 50/60Hz (auto switch), internal power supply |
Fogyasztás: | 35 watt (typ.) <1 watt in power save mode |
Basic: | Power, menu [1], down, up, select [2], mute |
OSD: | Auto image adjust, contrast, brightness, audio (volume, mute), ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K, User-RGB), information (resolution, H/V frequency, pixel clock, model number, serial number, website), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall |
Hőmérséklet: | 0°C – 40°C |
Páratartalom: | 10% – 90% (non-condensation) |
Net With Stand: | 5.2kg (with stand) |
Net Without Stand: | 4kg (without stand) |
Sync: | H/V separate (TTL) |
Analogue: | RGB analogue (0.7 Vp-p, 75 ohm) |
Frequency: | Fh: 30 ~ 82kHz, Fv: 50 ~ 85Hz |
Meets TCO’03 and Energy Star® standards |
Kensington® security port |
VESA® FPDM 100mm x 100mm |
Dönthető: | Down 5°, up 20° |
Height Adjustment: | 0 ~ 100mm |
