Típus: | 48cm / 19" TN colour TFT active matrix SXGA LCD |
Kontrasztarány: | 700:1 (typ.) |
Betekintési szögek: | 150° horizontal, 135° vertical (at 10:1) 160° horizontal, 150° vertical (at 5:1) |
Fényerő: | 300cd/m² (typ.) |
Display Area: | 37.6cm horizontal x 30.1cm vertical; 48.3cm diagonal |
Optimum Resolution: | 1280 x 1024@60Hz |
Válaszidő: | 5ms (off-on-off) (typ.) |
Fényforrás: | Long life, 50000 hrs. (typ.) |
Panel Surface: | Anti-glare (3H) |
Pixel Pitch: | 0.294mm |
Colour Support: | 16.7M colours (6-bit + 2-bit FRC) |
Pixel Clock: | 135MHz |
PC: | VGA up to 1280 x 1024 non-interlaced (@60Hz preferred) |
Mac®: | Power Mac™ up to 1280 x 1024 non-interlaced (@60Hz preferred) |
Physical With Stand: | 416 x 428 x 210 |
LCD Monitor, power cable, audio cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) |
Hangszóró: | 2 x 1 watt integrated invisible stereo speakers |
Analogue: | 15-pin mini D-Sub (attached cable) |
Teljesítmény: | 3-pin AC plug (CEE22) |
Audio (input/output): | 3.5mm stereo audio line-in |
Feszültség: | AC 100 – 240V, 50/60Hz (auto switch), internal power supply |
Fogyasztás: | <35 watt (max.), <1 watt in power save mode |
Basic: | Power, menu [1], up, down, select [2] |
OSD: | Auto image adjust, contrast, brightness, audio adjust (volume, mute), ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number, website), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language [English, Finnish, French, German, Italian, Japanese, Spanish, Simplified Chinese, Traditional Chinese], resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall |
Hőmérséklet: | 0°C – 40°C |
Páratartalom: | 10% – 90% (non-condensing) |
Net With Stand: | 4.6kg |
Bruttó: | 5.8kg |
Frequency: | Fh: 30 – 82kHz, Fv: 50 – 85Hz |
Sync: | H/V separated (TTL) |
Analogue: | RGB analogue (0.7 Vp-p, 75 ohm) |
Meets TCO’03 and ENERGY STAR standards |
Kensington® security port |
VESA FDMI 100mm x 100mm |
Dönthető: | Down 5°, Up 20° |
