Típus: | 43 cm / 17" Colour TFT Active Matrix SXGA LCD, TN Technology |
Kontrasztarány: | 500:1 (typ.) |
Betekintési szögek: | 140° horizontal, 130° vertical @10:1 160° horizontal, 155° vertical @ 5:1 |
Fényerő: | 300 cd/m² (typ.) |
Display Area: | 33.8cm horizontal x 27.0cm vertical, 43.2cm diagonal |
Optimum Resolution: | 1280 x 1024 |
Válaszidő: | 8ms (typ.) |
Panel Surface: | Anti-glare 3H |
Pixel Pitch: | 0.264mm |
Colour Support: | 16.2M colours (6-bit + 2-bit FRC) |
Pixel Clock: | 135MHz |
PC: | VGA up to 1280 x 1024 @ 75Hz (non interlaced) |
Mac®: | Power Mac™ up to 1152 x 870 @ 75Hz |
Fizikai méretek (SzxHxM): | 378 x 374 x 196 (W x H x D in mm) |
LCD Monitor, power cable, 15-pin VGA video cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/drivers) |
Signal: | 15-pin mini D-Sub (detachable cable) |
Teljesítmény: | 3-pin AC plug (CEE22) |
Feszültség: | AC 100-240V, 50-60Hz (auto-switch), internal power supply |
Fogyasztás: | <35W (typ.), <1W in suspend mode |
OSD: | Auto Image Adjust, Contrast, Brightness, Colour Adjust [sRGB, 9300K, 6500K (default), 5400K, User (R, G, B)], Information [Mode, Model Number, Serial Number, Website], Manual Image Adjust [H. Size, H./V. Position, Fine Tune, Sharpness, Scaling], Setup Menu [Language (English, French, German, Italian, Spanish, Finnish, Japanese, Simplified and Traditional Chinese), Resolution Notice, OSD Position, OSD Timeout, OSD Background], Memory Recall |
Physical: | Power on/off, menu, up, down, select |
Hőmérséklet: | 0–40°C |
Páratartalom: | 10–90% (non-condensing) |
Net: | 4.5kg |
Frequency: | Fh: 30-82kHz, Fv: 50-85Hz |
Analogue: | RGB Analogue (75 ohms, 0.7 Vp-p) |
Sync: | H/V separated (TTL) |
Meets TCO, ENERGY STAR and ENERGY standards. |
Down 5°, Up 20° |
