Black |
Kontrasztarány: | 1000:1 (typ.) / 20000:1 dynamic |
Betekintési szögek: | 170o (H), 160o (V) at 10:1 c/r, 170o (H) 170o (V) at 5:1 c/r |
Fényerő: | 300 cd/m² (typ.) |
Display Area: | 443 x 249 (mm) |
Optimum Resolution: | 1600×900 |
Válaszidő: | 5ms (typ.) |
Fényforrás: | 50,000 hrs (typ.) |
Panel Surface: | Anti-Glare, Hard coating (3H) |
Pixel Pitch: | 0.276mm(H) x 0.276mm(V) |
Colour Support: | 16.7 M (6-bits + Hi FRC) |
Size: | 50.80cm (20") wide Color TFT Active Matrix LCD 16:9 aspect ratio |
PC: | VGA up to 1600×900 Non Interlaced |
Mac®: | Power Mac, up to 1600×900 |
Physical With Stand: | 481 x 369 x 200 (mm), 18.94 x 14.51 x 7.86 (in) |
Physical Without Stand: | 481 x 288 x 64(mm), 18.94 x 11.32 x 2.52 (in) |
LCD display, VGA cable, Power cable, Quick Start Guide, ViewSonic Wizard CD |
Hangszóró: | W×2 |
Sync: | Separate Sync |
Analogue: | RGB Analog (75 ohms, 0.7 / 1.0 Vp-p) |
Frequency: | Fh: 24-82kHz, Fv: 50-75Hz |
Analogue: | 1×15 pin mini D-sub |
Teljesítmény: | Built-in power Adapter, 3-Pin plug |
Audio Input: | 1×3.5 mm Audio in |
Feszültség: | AC 100-240V (Universal); 50/60Hz(Switch) |
Fogyasztás: | 46 (typ) |
Eco Mode: | optimize 30W (typ.) / conserve 23W (typ.) |
Save mode: | ≦1W |
Basic: | [1], [2], Power, Down[▼], Up[▲] |
On View (PC mode): | Auto Image Adjust Contrast/Brightness Audio adjust: Volume mute Color Adjust: sRGB, 9300K, 7500K, 6500K, 5000K User Color: [R, G, B] Information Manual Image Adjust: H/V position, horizontal size, fine tune, sharpness, dynamic contrast, aspect ratio, Eco mode, setup menu, language select, resolution notice, OSD Position, OSD Time Out, OSD Background, memory recall. |
Hőmérséklet: | 41°F - 95°F (5°C - 35°C) |
Páratartalom: | 20 - 80% (Non condensed) |
Net: | 4.12kg (9.08lbs) |
Bruttó: | 5.21kg (11.49lbs) |
TCO'03, ENERGY STAR |
20° ~ -5° |
VESA 100mm x 100mm |
