Panel mérete: | 31.5'' diagonal |
Típus/ Technika: | TFT LCD Module with WLED Backlight |
Megjelenített terület (mm): | 698.4 (H) x 392.85 (V) mm |
Képarány: | 16:9 |
Felbontás: | 1920 x 1080 |
Colors: | 16.7 colors (8 bits) |
Fényerő: | 320 nits (typ.) |
Kontrasztarány: | 1200:1 (Typ.) ; 900:1 ( min.) |
Válaszidő: | 8 ms (typ.) |
Betekintési szögek: | H = 178, V = 178 (typ.) |
Backlight: | WLED |
Háttérvilágítás élettartama: | 30,000 Hours (typ.) |
Felületkezelés: | Anti-Glare, 3H, Haze 2% (typ) |
HDMI: | x2 (HDMI 1 has MHL) |
RGB / VGA: | x1 |
DVI: | x1 |
Audió: | x1 (L/R) |
CVBS/ Composite: | x1 (shared with Y) |
YPbPr/ Component: | x1 |
RS232: | x1 |
IR Passthrough: | x1 |
Audió: | x1 |
SPDIF: | x1 |
A típus: | x1 |
10Wx2 |
RGB PC/HDMI PC: | Up to 1920x1080 @60Hz |
CVBS: | 480i,576i |
YPbPr: | 480i, 480p,720p, up to 1080p |
HDMI: | 480i, 480p,720p, up to 1080p |
DVI: | Up to 1920x1080 @60Hz |
Physical- Top OSD: | Picture Mode Contrast Brightness Tint Color Blue Light Filter Color Temo Advance Zoom Mode DLC Sound Mode Bass Treble Digital Output Surround Sound AVC Balabce Sleep Timer Time Zone DST Time Format Clock Time Management Menu Language Transparent OSD Time Out Restore Default Sofeware Upgrade CEC BlueScreen Monitor ID HDMI Mode System Lock |
Feszültség: | 100-240VAC +/- 10% 50/60Hz Wide Range |
Fogyasztás: | 68W (max.); 41W (default) |
Wall Mount (VESA® ): | 100*200 mm (suggested screw: M4*L7 (C*D)) |
Temperature (º C): | 32°F to 104°F (0°C to 40°C) |
Páratartalom: | 15% ~ 90% @ 40°C Non-condensing. |
Physical w/stand (inch / mm): | 28.71 x 18.33 x 6.47/ 729.2 x 465.7 x 164.3 |
Physical w/o stand (inch / mm): | 28.71 x 16.92 x 1.91/ 729.2 x 429.7 x 48.5 |
Csomagolás (inch / mm): | 31.3 x 19.8 x 4.8/ 796 x 504 x 121 |
Net w/ stand (lb / kg): | 11.88/ 5.4 |
Net w/o stand (lb / kg): | 11.66/ 5.3 |
Bruttó (font / kg): | 15.84/ 7.2 |
**Warranty offered may differ from market to market |
1. Remote control with AAA batteries x2 2. Power cord (USx1 for VSA); (EUx1, UKx1 for VSE) 3. User Guide (CD, 4 languages, English/ French/Spanish/Simplified Chinese) 4. Quick Start Guid (Hared Copy, 1 languages, English for VSA) 5. Stand STND-043 *Actual content may differ from market to market |
