- Storage
Type: M.2 2280 SSD
Interface: SATA
Size: 128GB
- Interface
USB type-A: 4 x USB3.0
USB type-C: 1 x USB3.0
(DP out 4K@30Hz, USB3.0 upstream(In)),
12V/2A PD
Audio: 1 x Audio Combo Jack
Ethernet: 1 x RJ45 (10M/100M/1000M)
HDMI out: 1 x HDMI Video Out
(Support Video out 4K@60Hz,
CEC control - screen power on/off)
Antenna: Built-in (BT)
Power button: 1 x Power button
Power LED: 1 x Power LED
(Power on: Blue)
OS recovery: 1 x OS recovery
Kensington Security Lock: 1 x Security slot
- WIFI Expansion
WLAN spec: No Wi-Fi, BT5.3
- Operation System
Windows: Windows 11 IoT Enterprise (x64)
- Bundled Software
Software: Microsoft Teams Rooms
- Power
Supply mode: Internal power supply module
Input power: AC 100-240V 50/60Hz
Maximum power consumption: 111.9W (19V/5.89A)
Standby power consumption: 1.5W
Power Requirements: 12V/1.5A(Via TYPE-C)
Overall Power (Max.): 18W
Standyby Power: ≤0.5W
- Accessory (inbox)
Quick Start Guide: x1
VESA mounting bracket: x1
Power Cord: 1.8M x1
USB Type-C cable: 1.8m typeC x1
(include TypeC to A Plug adaptor)
Remote Control: Yes
Power adapter: 1
Wall mount components: 1
Screws: Yes
Lens Cover: 1
QSG: Yes
Compliance statement: Yes
- Physical Specifications
Dimension WxHxD: 9.01 x 10.85 x 1.69 in
230 x 275.5 x 43 mm
Dimension (package) WxHxD: 14.53 x 11.85 x 4.76 in
369 x 301x121mm
Net Weight: 1.86KG (4.10lb)
Gross Weight: 3.70kg (8.16lb)
Dimension LxHxD: 9.63 x 6.3 x 3.85 (in.)
245 x 160 x 98 (mm)
Dimension (package) LxWxH: 14.53 x 9.65 x 4.76 (in)
369 x 245 x 121 (mm)
Net Weight: 0.93kg (2.05lb.)
Gross Weight: 1.95kg (4.3lb.)
- Touch Console
MRC1010-TN
- Display
Size: 10.1 inch
Resolution: 1920*1200
Refreshing Frequency: 60Hz
NTSC: 72%
Back Light Unit: ELED
Brightness with glass(typ): 300cd/m ²
Life Time: 20000Hrs
- Operating System
System Version: Non-OS
- Touch System
Sensing Type: Capacitance touch recognition
Touch Tool: Finger
Accuracy: Middle:±1 mm;Edge:≤2.5mm
Touch Point: 10 points touch
Touch down latency: <25 ms
- I/O Port
USB 2.0: *1
HDMI Ingest: *1
Audio out: *1, 3.5mm interface
TYPE-C: "1
(DP in, USB downstream(3.0: HDMI signal, 2.0: Touch signal)"
- Sensor
Motion Sensor: PIR *1
(Support 24/7 continuous working when screen is off)
- Accessories
Quick Start Guide: *1
HDMI cable: 1 * 1.5M
Type-C cable: 1* 5M
- Video Bar System
UMB202
- Camera
Resolution: H.264/MJ: @30FPS
(1)3840×2160 (2)2560×1440
(3)1920×1080 (4)1280×720
(5)1024×576 (6)960×540
(7)800×600 (8)640×480
(9)640×360 (10)480×270
(11)352×288 (12)320×240
NV12 / YUY2: @30FPS
(1)1920×1080(2)1280×720
(3)640×360
Sensor: IMX577 1/2.3 inch, CMOS, 12M pixel
FOV: 117.8° (DFOV) ,109° (HFOV),74.4° (VFOV)
PTZ: EPTZ (5X digital Zoom)
Digital Noise Reduction: Yes
White Balance: Yes
Exposure: Yes
- Audio
Microphone array: 6 element, 8 meters pickup range
Speaker: mid-bass modulex1, treble module x1 in one box
(Maximum output 8W + 3W)
Output Power: 80 dBA @ 1000 Hz @ 1 meter at maximum volume
- I/O
USB-TypeC: 1
Audio Out: 1
DC 2.0 Power: 1
RJ45: 1 (Only for power supply)
IEEE 802.3 at,25.50W (max)
Power Button: Power Button: In startup mode, press the power button to mute.
In standby mode, press the power button to power on.
MIC Mute Button: Yes
- USB feature
Connection type: USB 3.0, downward compatible with USB2.0
Video Compression: MJPEG /YUY2 / H.264 / NV12
USB audio: 16K sampling rate, support UAC2.0
USB video communication protocol: UVC 1.1
UVC PTZ control: Support (Control Via Remote controller)
- Intelligent Function
Auto Framing: Yes
Voice tracking: Yes
- System Compatibility
OS: Windows 7 /8.1/10/11 or higher
macOS® 10.10 or higher
Google ChromebookTM Version 29.0.1547.70 or higher
Android
