Black |
Tipo: | 43cm / 17" TN colour TFT active matrix SXGA LCD |
Ratio de contraste: | 600:1 (typ.) |
Ángulos de visión: | 150° horizontal, 145° vertical (at 10:1) 170° horizontal, 155° vertical (at 5:1) |
Brillo: | 280cd/m² (typ.) |
Área de visualización: | 33.8cm (horizontal) x 27.0cm (vertical), 43.2cm diagonal |
Resolución óptima: | 1280 x 1024@60Hz |
Tiempo de respuesta: | 8ms (off-on-off) (typ.) |
Fuente de luz: | Long life, 50,000 hrs. (typ) |
Superficie del panel: | Anti-glare (3H) |
Tamaño del píxel: | 0.264mm |
Gama de colores: | 16.7M colours supported (6-bit + 2-bit FRC) |
Frecuencia de píxel: | 140MHz |
PC: | VGA up to 1280 x 1024 non-interlaced |
Mac®: | Power Mac™ up to 1280 x 1024 non-interlaced |
Físicas con la base: | 387 x 475-555 x 230 |
Físicas sin la base: | 387 x 367 x 67 |
Embalaje (LxAxP): | 445 x 552 x 278 |
TCO’03, GS, Ergo, ISO13406-2 (pixel failure class II), CE, CB, GOST-R, PSB, ENERGY STAR,YCO03, UL/cUL, FCC-B, ICES 003, NOM, TUV-S/IRAM/UL-AR S Mark, SASO, BSMI, C-Tick, MIC, CCC, WEEE, RoHS |
LCD Monitor, power cable, D-sub video cable, audio cable, Quick Start Guide, ViewSonic Wizard CD-ROM (User Guide/ drivers) (multi-language) |
Altavoces: | 2 x 1.5 watt integrated stereo speakers |
Analógico: | 15-pin mini D-Sub (detachable cable) |
Digital: | 24-pin DVI-D (detachable cable) |
Alimentación: | 3-pin AC plug (CEE22) |
Audio: | 3.5mm stereo audio line-in |
Voltaje: | AC 100–240V, 50/60Hz (auto switch), internal power supply |
Consumo: | 35 watt (typ.), <1 watt in power save mode |
Básico: | Power, menu [1], up, down, select [2], mute |
Menú en pantalla: | Auto image adjust, contrast, brightness, input select (D-sub, DVI-D), audio (volume, mute), ViewMatch® colour adjust (sRGB, 9300K, 6500K, 5400K, user RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), OSD/power lock, memory recall |
Temperatura: | 5°C–35°C |
Humedad: | 20%–80% (non-condensation) |
Neto con la base: | 5.0kg |
Bruto: | 6.9kg |
Frecuencia: | Fh: 30–82kHz, Fv: 50–75Hz |
Syncronización: | H/V separated (TTL) |
Analógico: | RGB analogue (0.7/1.0 Vp-p, 75 ohm) |
Digital: | DVI-D (TMDS, 100 ohms) |
Meets TCO’03 and ENERGY STAR standards |
Kensington security port |
VESA FDMI 100mm x 100mm |
Inclinación: | Down 5°, up 20° |
Giratoria: | 360° swivel base |
Ajuste de altura: | 0~80mm |
