Product Overview
Ready-To-Use Kit
The included Direct View LED display comes with preassembled LED modules, cabinets, a system control box, mobile cart and flight case. It can be set up and ready to use within just a few minutes, saving time and effort as well as lowering the technical barrier for installers. The flight case provides convenient storage and ample protection for the display during transport.
Foldable Screen
A foldable screen design allows the display to be packed into its custom flight case, making it easy to set up and share between classrooms, conference rooms, auditoriums, and other areas around a school or business.
Motorized Height Adjustment
The mobile cart includes a motorized height adjustment feature that raises the display up to 25 inches with the simple press of a button. This added versatility provides better visibility whether the display is placed on a stage or in a conference room, and a variety of other scenarios.
Freedom of Movement
The mobile cart also includes 360° silent wheels that allow you to move the display freely, and quitely, whenever you need to. The wheels easily lock so that everything remains steady and in place.
Enhanced LED Durability with Glue-on-Board Surface Treatment
This display uses Glue-on-Board (GOB) technology, a protective shield that safeguards the LEDs during installation and daily use. Its IP54 rating ensures resistance to bumps, dust, and moisture, making it perfect for busy public spaces such as auditoriums, lecuture halls, gymnasiums and more.
Multiple Inputs on One Screen
An intuitive split-screen function makes video conferences and online collaborations more flexible and creative. The display also supports Picture-by-Picture (from up to 4 different inputs) or Picture-in-Picture (a screen within another screen) scenarios in real-time.*
*PBP and PIP require HDMI source input.
Wireless Content Sharing
The pre-installed ViewBoard Cast™ enables content to be streamed from mobile devices onto the display over wireless networks, whether one-to-one or many-to-one.
Simple and Easy Setup
From the LED tiles, to the AV hardware and software, power supplies and cables, this all-in-one solution includes everything you need in one box for streamlined installation.
Sturdy and Durable Flight Case
The included flight case not only provides secure protection of the Direct View LED display, but also makes for swift and effortless delivery from one venue to another.
Impressive in any Venue
With a huge 135" screen size, 1.5mm fine pixel pitch, slim profile, and ultra-narrow bezel, the Direct View LED display delivers a stunning, all-in-one alternative to a conventional video wall. Larger than four 67-inch LCD displays combined, this display seamlessly delivers content without lines or distortion for a more immersive visual experience.
Quick and Convenient Module Replacement
Instead of moving an entire display around for maintenance, the hot-swappable front LED modules allow users to change any defective piece. An included vacuum maintenance tool uses suction to easily remove and replace LED modules.
3-Year Limited Warranty
Have peace of mind in the quality and reliability of your ViewSonic display—backed by one of the industry’s best pixel performance policies and a 3-year limited warranty with onsite service.
June 2024
- OS: Android 9.0
- GPU: Mult-core MaliG51 MP2
- CPU: MTK9669
- Memory: 4GB DDR4
- Storage: 64GB (56GB available)
- Internal Speakers: 20W (x2)
- PC Resolution (max): 1920x1080
- Mac® Resolution (max): 1920x1080
- HDMI 1.4 In: 2
- HDMI 2.0 In: 3
- HDMI 2.1 In: 1
- HDMI 2.0 Out: 2
- 3.5mm Audio Out: 1
- USB 2.0: 3
- USB Type C: 1 (Video input, and Power 5V/2A)
- RS232: 1
- RJ45 Input (Internet): 1
- IR in: 1
- WIFI Module Slot: 1
- Intel® OPS Slot In (80-pin): 1
- Voltage: 100-120V+/- 10%, 50/60Hz, 20A
- Consumption (max): 2000W
- Consumption (typical): 900W
- Stand-by: <0.5W
- On Screen Display: Yes
- Remote Control: Yes
- Temperature: 32-104º F (0 - 40º C)
- Humidity (non-condensing): 20-80%
- Net (lbs): 548.95
- Gross (lbs): 939.0
- Net (kg): 249.0
- Gross (kg): 426.0
- Packaging (in.): 74.8 x 80.8 x 31.5
- Physical (in.): 70.9 x 79.6 x 29.9 (min.), 118.5 x 105.9 x 29.9 (max.)
- Packaging (mm): 1900.0 x 2052.0 x 800.0
- Physical (mm): 1800.0 x 2023.0 x 760.0 (min.), 3010.0 x 2690.0 x 760.0 (max.)
- Warranty: 3-year limited warranty on parts and labor, on-site service
- Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
- Package Contents: Power Cord, Remote Control, QSG, Maintenance Tool (LD-MK-001) x 1, LAN Cable (16ft; Cat 5A) x 1, IR Extender Cable x 1
- Regulations: cTUVus, FCC, RoHS
- Wifi: 2.4G/5G Hz
- Display Type: Direct View LED
- Screen Size: 135
- Viewable Area (in.): 135
- LED Pitch Size (mm): 1.56
- LED Grayscale: 14 bits
- Backlight Life (Hours): 100,000
- Viewing Angles: 170º horizontal, 170º vertical
- Operation Rating: 24/7
- Display Resolution: 1920 x 1080
- Aspect Ratio: 16:9
- Light Source: Fine Pixel Pitch LED
- Brightness: 450 cd/m2
- Static Contrast Ratio: 6,000:1
- Refresh Rate: 3,840Hz
