Product Overview
*Certification for Microsoft Teams pending - expected completion by second quarter, 2024.
Inclusive and Immersive Meetings
Powerful 4K Ultra HD resolution and 5x digital zoom, combined with voice and camera tracking, allows you to switch between wide-angle, full room views, and individual speaker tracking. This ensures that meeting participants always know who is speaking, leading to better conversations and better conference calls.
Enhanced Meeting Equity with Wide-Angle Lens
An auto-adjustable EPTZ (electronic pan-tilt-zoom) and 120° wide-angle lens ensures all attendees are in the frame, regardless of where they are in the room. In addition, advanced lens technology delivers remarkable video quality with outstanding resolution and fine detail. These features are essential for achieving meeting equity as they ensure that everyone can perceive facial expressions, body language, and other visual cues accurately.
Clear Audio and Communication
A built-in beamforming 6-microphone array accurately captures voices from up to 26 feet away. State-of-the-art 3A audio (AEC/ANS/AGC) processing technology provides echo cancellation, noise reduction, and automatic gain control, ensuring clear and accurate communication every time.
Easy and Flexible Installation
Versatile mounting options allow for easy setup in nearly any meeting space. This camera has DC 2.0 power input and RJ45 PoE power supply for easy installation.
- Warranty: Three-year limited warranty on parts, labor and backlight
- Regulations: CE, FCC, IC ID, FCC ID, LVD, CA65, TSCA, RoHS
- Package Contents: USB Type-C cable (1.8m), Remote Control, Power adapter, Wall mount components, Screws, Quick Start Guide (QSG), Compliance statement
- USB 3.0 Type C: 1
- Power: Power DC 2.0 Jack: Power Jack, EITA type DC Input 12V
- Audio Out: 1 (3.5mm)
- LAN/Ethernet: For POE only, 802.3at
- System Compatibility: Windows 7/8.1/10/11 or higher, macOS® 10.10 or higher, Google Chromebook™ Version 29.0.1547.70 or higher, Android
- Software Compatibility: Microsoft Teams, Zoom, Google Meet, Google Hangouts, Cisco WebEx, RingCentral and many more
- Voltage: 12V
- Consumption: 10W
- Capacity: Storage 128GB SATA SSD (M.2-2280 SATA3 up to 6Gb/s)
- Channel: 1.1
- AUDIO OUTPUT: 8W speaker, 3W subwoofer
- Maximum Sound Pressure: 80dB SPL@1m
- Signal to Noise Ratio: >75dB
- Frequency Range: 150Hz ~ 18kHz
- Audio features: Noise Reduction, Echo Cancellation, Anti-Reverberation, Built-in AGC Algorithm
- Microphone array: 6 microphones
- Microphone Frequency: 100Hz ~ 7.5kHz
- Microphone Voice Pickup Range: 26.24 ft. (8m)
- Motion Sensor: PIR x1 (Support 24/7 continuous working when screen is off)
- Pixels: 12M
- Zoom: 5x digital zoom
- Field of View (FOV): 120° (DFOV), 109° (HFOV), 74.4° (VFOV)
- Adjustable Angle: +/- 15° (V)
- Focus Mode: Fixed Focus
- Output Format: MPJG; YUY2; H.264
- Focus Distance: 3.28 ft. (1m)
- Sensor: Sony IMX577 1/2.3-inch CMOS
- Camera Resolution/Frame Rate: Maximum 4K@30Hz, 1080p@60Hz
- Temperature: 32°F ~ 104°F
- Storage Temperature: -40°F ~ 140°F
- Humidity: 10%-90%
- Storage Humidity: Non-condensing 20% ~ 90% R.H.
- Altitude: Below 5,000m
- Physical (in.): 18.2 x 3.0 x 3.7
- Net (lbs): 2.3
- Gross (lbs): 5.6
-
