Versatile Enterprise Digital Signage
CDE12 Series

With 4K Ultra HD screens available in a range of sizes, the ViewSonic CDE12 series of digital displays allow you to deliver messages with maximum impact. By investing in a ViewSonic CDE12 display today, you will lower your total cost of ownership thanks to premium performance at a great price, commercial-grade durability, and an industry-leading warranty.

a number of different screen sizes are showna number of different screen sizes are shown

Stunning 4K Ultra HD Resolution

With large screen sizes ranging from 43” to 75” and four-times the resolution of Full HD, these displays are ideal for delivering stunning 4K video and images to grab attention in large spaces such as busy lobbies, transportation hubs, public areas and more.

Versatile Usage Scenarios

CDE12 displays are not only ideal for use as digital signage displays across your organization, but they are great value options for meeting collaboration as well. Integrated ViewBoard Cast™ screen sharing software and ViewSonic Display™ app allows up to four participants to connect and share content, regardless of operating system.

a number of people connected to a display at once using a cariety of different devicesa number of people connected to a display at once using a cariety of different devices
a diagram showing a computer connecting to displays via either USB or RJ45a diagram showing a computer connecting to displays via either USB or RJ45

Content Management Software

Great for all venues and scenarios, optional Signage Manager software lets users transfer multimedia content onto the display from PCs and laptops. This content management tool also lets you format, schedule, and save playback settings.

Device Management

ViewSonic Manager™ is a cloud-based management solution that empowers IT administrators to remotely monitor devices, manage apps, push out broadcasts and more within the myViewBoard® ecosystem. Manager lets IT administrators seamlessly monitor and maintain individual displays across large organizations from a single control panel.

a computer connected to a number of displays wirelesslya computer connected to a number of displays wirelessly
a variety of connector types in a board rooma variety of connector types in a board room

Versatile Connectivity

A range of connectivity options include USB-C, HDMI, LAN and more for added versatility and convenience. Plus, a pre-installed and removable Wi-Fi plug-in module provides a robust and reliable wireless presentation experience.

Peace of Mind

These displays are covered by an industry-leading 3-year limited standard warranty with on-site service (4th and 5th year extended warranties are available as upgrade options).*

*Subject to ViewSonic’s standard limited warranty and on-site service terms and conditions.

three year limited warranty logothree year limited warranty logo

CDE4312

43” 4K Digital Display

CDE5512

55” 4K Digital Display

CDE6512

65” 4K Digital Display

IFP9850IFP9850

CDE7512

75” 4K Digital Display

Display Size
43"
55"
65"
75"
75"
Model
CDE4312
CDE5512
CDE6512
CDE7512
CDE7512-2
Resolution
3840 x 2160
3840 x 2160
3840 x 2160
3840 x 2160
3840 x 2160
Brightness (typ.)
230-nits
290-nits
290-nits
330-nits
330-nits
Features
Operation Rating
16/7
16/7
16/7
16/7
16/7
Orientation
Landscape
Landscape
Landscape
Landscape
Landscape
Daisy-chain/Tiling
No
No
No
No
No
PIP/PBP
No
No
No
No
No
USB-C (Video/Power/USB/LAN)
Yes (15W PD)
Yes (15W PD)
Yes (15W PD)
Yes (15W PD)
Yes (15W PD)
Input/Output
HDMI
2
2
2
2
2
HDMI Out
0
0
0
0
0
USB Type-C
1
1
1
1
1
DP
Optional Adapter (USB-C)
Optional Adapter (USB-C)
Optional Adapter (USB-C)
Optional Adapter (USB-C)
Optional Adapter (USB-C)
VGA
0
0
0
0
0
RS232
1
1
1
1
1
LAN
1
1
1
1
1
IR
1
1
1
1
1
Intel® OPS Slot
No
No
No
No
No
Wi-Fi / Bluetooth
Yes (removable)
Yes (removable)
Yes (removable)
Yes (removable)
Yes (removable)
Speakers
Stereo (Left/Right)
10W x2
10W x2
10W x2
10W x2
10W x2
Bezel Width
Left/Right/Top/Bottom
15/15/15/20 mm
16/16/16/24 mm
16/16/16/22 mm
16/16/16/19 mm
16/16/16/19 mm
Wall Mount
VESA® Pattern
200 x 200 (M6 x 10mm)
200 x 200 (M6 x 10mm)
300 x 200 (M6 x 10mm)
600 x 400 (M8 x 10mm)
400x300 (M8 x 16mm)
Smart Display
Android OS
11.0
11.0
11.0
11.0
11.0
CPU
ARM Cortex A53
ARM Cortex A53
ARM Cortex A53
ARM Cortex A53
ARM Cortex A53
GPU
Quad-Core (1.5GHz)
Quad-Core (1.5GHz)
Quad-Core (1.5GHz)
Quad-Core (1.5GHz)
Quad-Core (1.5GHz)
RAM
2GB
2GB
2GB
2GB
2GB
Storage
16GB
16GB
16GB
16GB
16GB
USB Media Playback
Yes
Yes
Yes
Yes
Yes
vCast™
Yes
Yes
Yes
Yes
Yes
myViewBoard Display™
Yes
Yes
Yes
Yes
Yes
myViewBoard Manager™
Yes
Yes
Yes
Yes
Yes
AV Control System
Crestron
Compatible
Compatible
Compatible
Compatible
Compatible
Extron
Compatible
Compatible
Compatible
Compatible
Compatible
AMX
Compatible
Compatible
Compatible
Compatible
Compatible
NDAA
Compliant
Yes
Yes
Yes
Yes
Yes
